  9. Rectangular Power Connector, 15 Contact(S), Male And Female, Crimp Terminal, Plug
This item is Discontinued.
Molex Rectangular Power Connector, 15 Contact(S), Male And Female, Crimp Terminal, Plug 50841155

Rectangular Power Connector, 15 Contact(S), Male And Female, Crimp Terminal, Plug (Discontinued)

  • Mfr # 50841155
  • Zoro # G105913073
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
50841155
Zoro #
G105913073
UPC #
-
Country of Origin
India

Details

Item
Wire Connector
Color
Natural
Number of Rows
5
Insulation Material
Nylon
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Material
Nylon
Standards
CSA Certified; UL E29179
Connector Type
Plug
Series
42021
Hole Center to Center
6.35 mm
Application
Power, Wire-to-Board, Wire-to-Wire
Current Rating
11 A; 20 A
Number of Contacts
15
Max. Temp.
105°C
Flammability Rating
UL 94V-0
Material - Resin
Nylon
Pitch - Mating Interface
6.35mm
Current - Maximum per Contact
11.0A, 20.0A
Flammability
94V-0
Glow-Wire Capable
No
Lock to Mating Part
Yes
Temperature Range - Operating
-55° to +105°C
CSA
LR19980
UL
E29179
Stackable
No
Circuits Detail
15
Polarized to Mating Part
Yes
Keying to Mating Part
None
Product Name
MLX
