- MFR #
- 459841482
- Zoro #
- G705963935
- UPC #
- 822350773225
- Country of Origin
- United States
- Item
- Power Connector
- Color
- Black
- Max. Voltage
- 250V AC
- Maximum Voltage
- 250 V
- Application
- Board-to-Board, Power
- Current
- 20 A
- Series
- 45984
- Standards
- CSA Certified; UL E29179
- Maximum Operating Temperature
- 260 Degrees C
- UL 94 Flammability Rating
- V-0
- Material
- High Temperature Thermoplastic
- Hole Center to Center
- 1.27 mm, 12 mm
- Number of Contacts
- 50
- Features
- Surface Mount Compatible
- Current Rating
- 20 A
- Sub-Category
- PCB Receptacles
- Contact Finish
- Gold Plated
- Number of Rows
- 2
- Max. Temp.
- 260°C
- Terminal Type
- Through Hole
- Terminal Finish
- Tin Plated
- Flammability Rating
- UL 94V-0
- Material - Plating Mating
- Gold
- Product Name
- EXTreme LPHPower
- Pitch - Mating Interface
- 1.27mm, 12.00mm
- Max-Duration
- 20
- Grounding to PCB
- No
- CSA
- LR19980
- Glow-Wire Capable
- No
- Max-Cycle
- 3
- Polarized to PCB
- Yes
- Plating min - Mating
- 0.762µm
- Keying to Mating Part
- Yes
- (p)ower-(s)ignal Configuration
- 10p - 40s
- Guide to Mating Part
- Yes
- Material - Metal
- High Performance Alloy (HPA)
- Stackable
- No
- Component Type
- PCB Receptacle
- Circuits (Loaded)
- 50
- Current - Maximum per Contact
- 20.0A
- Material - Plating Termination
- Tin
- PCB Locator
- Yes
- Orientation
- Right Angle
- Durability (mating cycles max)
- 250
- Max-Temp
- 260
- Temperature Range - Operating
- -40° to +105°C
- Flammability
- 94V-0
- Lock to Mating Part
- No
- UL
- E29179
- Material - Resin
- High Temperature Thermoplastic
- Polarized to Mating Part
- Yes
- PCB Retention
- Yes
