  11. Wire Connector, 6 Port, Black, High Temperature Thermoplastic Insulation, 30 V AC/DC, 0.5 A
Molex Wire Connector, 6 Port, Black, High Temperature Thermoplastic Insulation, 30 V AC/DC, 0.5 A 1715653003 - main

Wire Connector, 6 Port, Black, High Temperature Thermoplastic Insulation, 30 V AC/DC, 0.5 A

  • Mfr # 1715653003

  • Zoro # G505788950

product price: $144.99
/ea
Free Shipping & Returns

Key Features

Color
Black
Insulation Material
High Temperature Thermoplastic
Maximum Voltage
30 V AC/DC
Current
0.5 A
Minimum Operating Temperature
-40 Degrees C
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1715653003
Zoro #
G505788950
UPC #
-
Country of Origin
Indonesia

Dimensions

Contact Plating Thickness
0.762 µm
PC Tail Length
1.20mm
PCB Thickness - Recommended
1.57mm

Details

Item
Wire Connector
Color
Black
Insulation Material
High Temperature Thermoplastic
Maximum Voltage
30 V AC/DC
Current
0.5 A
Minimum Operating Temperature
-40 Degrees C
Maximum Operating Temperature
85 Degrees C
Number of Ports
6
UL 94 Flammability Rating
V-0
Series
171565
Standards
UL E29179
Material
Copper
Number of Contacts
228
Finish
Gold Plated
Hole Center to Center
0.8 mm
Number of Rows
2
Application
Board-to-Board, Module-to-Board, Wire-to-Board
Terminal Finish
Matte Tin Plated
Orientation
Right Angle
Lock to Mating Part
Yes
Material - Plating Termination
Matte Tin
Durability (mating cycles max)
100
Polarized to Mating Part
Yes
Data Rate
28.0 Gbps
Plating min - Mating
0.762µm
Pitch - Mating Interface
0.80mm
Polarized to PCB
Yes
PCB Retention
Yes
Keying to Mating Part
None
PCB Locator
Yes
Circuits (Loaded)
228
Grounding to Panel
Yes
Material - Plating Mating
Gold
