Ambient Relative Humidity
5 to 95% (non-condensing)
Connector
CN2610/2650: 8-pin RJ45; CN2650I: DB9 male, 8-pin RJ45
Linux Real TTY Drivers
Linux 2.4.x, 2.6.x, 3.x
RS-485-4w
Tx+, Tx-, Rx+, Rx-, GND
Storage temperature
Standard Models: -40 to 75°C (-40 to 167°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F); High Voltage Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Pull High/Low Resistor for RS-485
1 kΩ, 150 kΩ
Number of Ports
8 or 16, 2 (2 IPs)
IP Routing
Static, RIP-I, RIP-II
Freefall
IEC-68-2-34, IEC-68-2-32
Windows Real COM Drivers
Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded
Console Port
Dedicated RS-232 console port on rear panel (8-pin RJ45)
Standard
Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS, Redundant COM, Disabled
Configuration Options
Web Console, Serial Console, Telnet Console, Windows Search Utility
RS-485-2w
Data+, Data-, GND
EMI
EN 55022 Class A, FCC part 15 Subpart B Class A
Terminator for RS-485
120 Ω
Safety
UL 60950-1, EN 60950-1
RS-485 Data Direction Control
ADDC® (Automatic Data Direction Control)
RS-232
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Serial Standards
CN2610: RS-232; CN2650/2650I: RS-232/422/485
Operating temperature
Standard Models: 0 to 55°C (32 to 131°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F); High Voltage Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Serial Line Protection
2 kV optical isolation (CN2650I)
Power Consumption
CN2650 AC models: 235 mA @ 100 VAC, 145 mA @ 240 VAC; CN2650I HV models: 152 mA @ 88 VDC, 86 mA @ 300 VDC
Input Voltage
AC Models: 100 to 240 VAC, 47 to 63 Hz; DC Models: 110 VDC (88 to 300 VDC)
Magnetic Isolation
1.5 kV built-in
Power Line Protection
1 kV burst (EN 61000-4-4: EFT/B), 2 kV surge (EN 61000-4-5)
Flow Control
RTS/CTS, DTR/DSR, XON/XOFF
Network Protocols
ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP, HTTP, SMTP, ARP, PPPoE, DDNS
Parity
None, Even, Odd, Space, Mark
Speed
10/100 Mbps, auto MDI/MDIX
Security Protocols
RADIUS, HTTPS, SSH, PAP, CHAP
Automatic Reboot Trigger
Built-in WDT (watchdog timer)
Baudrate
50 bps to 921.6 kbps
EMS
EN 61000-4-2 ESD: contact 4 kV; air 8 kV; EN 61000-4-3 RS: 3 V/m (80 MHz to 1 GHz); EN 61000-4-4 EFT: Power 4 kV; Signal 2 kV; EN 61000-4-5 Surge: AC 1 kV (AC models); DC 2 kV (HV models); Signal 1 kV; EN 61000-4-6 CS: 3 V; EN 61000-4-8; EN 61000-4-11: AC m
Terminal Sessions
8 sessions per port
MTBF (mean time between failures)
CN2650I AC models: 99,320 hrs; CN2650I-8-HV-T: 191,326 hrs; CN2650I-16-HV-T: 116,924 hrs
Fixed TTY Drivers
SCO Unix, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
Alert Tools
Built-in buzzer and RTC (real-time clock)
RS-422
Tx+, Tx-, Rx+, Rx-, GND
