  11. Active Ethernet I/O Server, 8Ai/2Ao, Iologik E2240
This item is Discontinued.
Moxa Active Ethernet I/O Server, 8Ai/2Ao, Iologik E2240 ioLogik E2240

Active Ethernet I/O Server, 8Ai/2Ao, Iologik E2240 (Discontinued)

  • Mfr # ioLogik E2240
  • Zoro # G4575237
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E2240
Zoro #
G4575237
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Analog Outputs
2 channels
Parity
None
Load Resistor
Less than 250 ohms
Protocol
Modbus/RTU
Ambient Relative Humidity
5 to 95% (non-condensing)
Baudrate
1200 to 115200 bps
Type
Differential input
Wiring
I/O cable max. 14 AWG
Input Range
±150 mV, ±500 mV, ±5 V, ±10 V, 0 to 20 mA, 4 to 20 mA
Accuracy
±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
Output Range
0 to 10 V, 4 to 20 mA
Resolution
16 bits, 12 bits
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Stop Bits
1
Data Bits
8
Analog Inputs
8 channels
I/O Mode
Voltage / Current
Input Impedance
900k ohms (min.)
Serial Line Protection
15 kV ESD for all signals
Power Input
24 VDC nominal, 12 to 36 VDC
Sampling Rate
All channels: 10 samples/sec for voltage; 6 samples/sec for current; Per channel: 1.25 samples/sec for voltage; 0.75 samples/sec for current; Single channel: 1.25 samples/sec for voltage; 0.75 samples/sec for current
Shock
IEC 60068-2-27
Altitude
Up to 2000 m
Ethernet
1 10/100 Mbps RJ45 port
Drive Voltage
15 VDC for current output
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Protection
1.5 kV magnetic isolation
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Time
155,941 hrs
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Isolation
3k VDC or 2k Vrms
Vibration
IEC 60068-2-6
Built-in Resistor for Current Input
120 ohms
Power Consumption
198 mA @ 24 VDC
Database
Telcordia (Bellcore)
Storage temperature
-40 to 85°C (-40 to 185°F)
Safety
UL 508
Freefall
IEC 60068-2-32

Description

Active Ethernet I/O Server, 8AI/2AO
