  11. Active Ethernet I/O Server, 8Di/8Do/4Dio
This item is Discontinued.
Moxa Active Ethernet I/O Server, 8Di/8Do/4Dio ioLogik E2212

Active Ethernet I/O Server, 8Di/8Do/4Dio (Discontinued)

  • Mfr # ioLogik E2212
  • Zoro # G4573749
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E2212
Zoro #
G4573749
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Counter Frequency
900 Hz
Ambient Relative Humidity
5 to 95% (non-condensing)
Pulse Output Frequency
1 kHz
Digital Outputs
8 channels
Vibration
IEC 60068-2-6
Altitude
Up to 2000 m
Over-current Protection
2.6 A (4 channels @650 mA)
Shock
IEC 60068-2-27
Dry Contact
On: short to GND; Off: open
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Freefall
IEC 60068-2-32
I/O Mode
DI or Event Counter, DO or Pulse Output
Ethernet
1 10/100 Mbps RJ45 port
Current Rating
200 mA per channel
Database
Telcordia (Bellcore)
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Parity
None
Stop Bits
1
Wiring
I/O cable max. 14 AWG
Data Bits
8
Storage temperature
-40 to 85°C (-40 to 185°F)
Safety
UL 508
Wet Contact (DI to GND)
On: 0 to 3 VDC; OFF: 10 to 30 VDC
Common Type
6 points per COM
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Protocol
Modbus/RTU
Sensor Type
Wet Contact (NPN or PNP) and Dry Contact
Power Input
24 VDC nominal, 12 to 36 VDC
Time
217,722 hrs
Digital Inputs
8 channels
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Protection
1.5 kV magnetic isolation
Isolation
3k VDC or 2k Vrms
Over-voltage Protection
45 VDC
Serial Line Protection
15 kV ESD for all signals
Configurable DI/Os
4 channels
Over-temperature Shutdown
175°C (min.)
Digital Filtering Time Interval
Software Configurable
Type
Sink
Baudrate
1200 to 115200 bps
Power Consumption
136 mA @ 24 VDC
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP

Description

Active Ethernet I/O Server, 8DI/8DO/4DIO
