  11. Active Ethernet I/O Server, 8Tc/4Do, -40 To 75 Deg.C
This item is Discontinued.
Moxa Active Ethernet I/O Server, 8Tc/4Do, -40 To 75 Deg.C ioLogik E2262-T

Active Ethernet I/O Server, 8Tc/4Do, -40 To 75 Deg.C (Discontinued)

  • Mfr # ioLogik E2262-T
  • Zoro # G4571536
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E2262-T
Zoro #
G4571536
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Protection
1.5 kV magnetic isolation
Pulse Output Frequency
100 Hz
Current Rating
200 mA per channel
Stop Bits
1
Data Bits
8
Database
Telcordia (Bellcore)
Type
Sink
Vibration
IEC 60068-2-6
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Storage temperature
-40 to 85°C (-40 to 185°F)
Over-current Protection
2.6 A (4 channels @ 650 mA)
Input Impedance
1 M ohms
Time
341,063 hrs
Sampling Rate
12 samples/sec (all channels)
Ethernet
1 10/100 Mbps RJ45 port
Thermocouple Inputs
8 channels
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Digital Outputs
4 channels
I/O Mode
DO or Pulse Output
Serial Line Protection
15 kV ESD for all signals
Wiring
I/O cable max. 14 AWG
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Resolution
16 bits
Protocol
Modbus/RTU
Millivolt Type
Mode: ±78.126 mV, ±39.062 mV, ±19.532 mV; Fault and over-voltage protection: -35 to +35 VDC (power off); -25 to +30 VDC (power on)
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Sensor Type
J (0 to 750°C), K (-200 to 1250°C), T (-200 to 350°C), E (-200 to 900°C), R (-50 to 1600°C), S (-50 to 1760°C), B (600 to 1700°C), N (-200 to 1300°C)
Parity
None
Freefall
IEC 60068-2-32
Ambient Relative Humidity
5 to 95% (non-condensing)
Over-voltage Protection
45 VDC
Isolation
3k VDC or 2k Vrms
Altitude
Up to 2000 m
Baudrate
1200 to 115200 bps
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Accuracy
±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
Over-temperature Shutdown
175°C
Power Input
24 VDC nominal, 12 to 36 VDC
Safety
UL 508
Shock
IEC 60068-2-27
Power Consumption
160 mA @ 24 VDC

Description

Active Ethernet I/O server, 8TC/4DO, -40 to 75°C
