Entry-Level Indust. Media Converter, Multi Mode, St, -10 To 60 DegreeC

  • Mfr # IMC-21-M-ST

  • Zoro # G4395720

product price:  $281.99
/ea
Free Shipping & Returns

Key Features

Standards
MIL-HDBK-217F
Depth
3.8 in
Height
1 in
Width
4.3 in
Product Series
IMC21
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
IMC-21-M-ST
Zoro #
G4395720
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Depth
3.8 in
Height
1 in
Width
4.3 in
Optical Wavelength
1300 nm
Dimensions
25 x 109 x 97 mm (0.98 x 4.29 x 3.82 in)

Details

Standards
MIL-HDBK-217F
Product Series
IMC21
Product Name
IMC-21 Fast Ethernet Media Converter
Number of Network (RJ-45) Ports
1
Environmentally Friendly
Yes
Product Type
Transceiver/Media Converter
Number of ST Ports
1
Maximum Distance Supported
3.11 Mile
Form Factor
Rack-mountable
Network (RJ-45)
Yes
Fiber Optic Cable Standard
50/125 µm
Weight (Approximate)
4.41 oz
Network Technology
10/100Base-TX, 100Base-FX
Total Number of Ports
2
IP Rating
IP30
EMS
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV;IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m;IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV;IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV;IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m;IEC 61000-4-8 PFMF;IEC 61000-4-11
Ambient Relative Humidity
5 to 95% (non-condensing)
Operating Temperature
-10 to 60°C (14 to 140°F)
Housing
Plastic
EMI
CISPR 32, FCC Part 15B Class A
IEC 61000-4-5 Surge
Power: 1 kV; Signal: 1 kV
Magnetic Isolation Protection
1.5 kV (built-in)
Safety
EN 60950-1, UL 60950-1
Storage Temperature (package included)
-40 to 70°C (-40 to 158°F)
Vibration
IEC 60068-2-6
Input Voltage
12 to 48 VDC
IEC 61000-4-3 RS
80 MHz to 1 GHz: 3 V/m
Input Current
271 mA @ 12 to 48 VDC
100BaseFX Ports (multi-mode ST connector)
IMC-21-M-ST: 1
IEC 61000-4-4 EFT
Power: 1 kV; Signal: 0.5 kV
Overload Current Protection
Supported
Installation
DIN-rail mounting
IEC 61000-4-2 ESD
Contact: 6 kV; Air: 8 kV
Power Consumption
271 mA @ 12 to 48 VDC
IEC 61000-4-6 CS
150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m
EMC
EN 55032/24
Environmental Testing
IEC 60068-2-1;IEC 60068-2-2;IEC 60068-2-3

Description

Entry-level Industrial Media Converter, multi mode, ST, -10 to 60°C
