  11. Ethernet Remote I/O, M12 Connector, 4 Dis, 4 Dios, -40 To 85 Degrees C
This item is Discontinued.
Moxa Ethernet Remote I/O, M12 Connector, 4 Dis, 4 Dios, -40 To 85 Degrees C ioLogik E1512-M12-T

Ethernet Remote I/O, M12 Connector, 4 Dis, 4 Dios, -40 To 85 Degrees C (Discontinued)

  • Mfr # ioLogik E1512-M12-T
  • Zoro # G4570075
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E1512-M12-T
Zoro #
G4570075
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
144 x 124 x 30 mm (5.67 x 4.88 x 1.18 in)

Details

Mounting
DIN rail (standard), wall (with optional kit)
Isolation
3K VDC or 2K Vrms
Configurable DI/Os
4 channels
Vibration
IEC 60068-2-6
Over-voltage Protection
45 VDC
Common Type
2 points per COM (Configurable DI/Os)
Current Rating
200 mA per channel
EMI
EN 61000-3-2, EN 61000-3-3, EN 61000-6-4, FCC Part 15 Subpart B Class A
Type
Sink
Pulse Output Frequency
500 Hz
Digital Filtering Time Interval
Software Configurable (minimum: 1 millisecond)
Safety
UL 508
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, HTTP
Wiring
I/O cable max. 14 AWG
Ethernet
1 10/100 Mbps, M12
Over-temperature Shutdown
175°C (typical), 150°C (min.)
Dry Contact
On: short to GND; Off: open
Over-current Protection
2.6 A (4 channels @ 650 mA)
Counter Frequency
250 Hz
Sensor Type
Wet Contact (NPN or PNP), Dry Contact
Power Input
24 VDC nominal, 12 to 48 VDC
Operating temperature
-40 to 85°C (-40 to 185°F)
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
I/O Mode
DO or Pulse Output, DI or Event Counter
Digital Inputs
4 channels (channel-to-channel isolation)
Storage temperature
-40 to 85°C (-40 to 185°F)
Freefall
IEC 60068-2-32
Rail Traffic
EN 50155*, EN 50121-3-2, EN 50121-4
Shock
IEC 60068-2-27
Power Consumption
149 mA @ 24 VDC
Ambient Relative Humidity
5 to 95% (non-condensing)
Altitude
Up to 2000 m
EMS
EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11; EN 61000-6-2
Protection
1.5 KV magnetic isolation

Description

Ethernet remote I/O, M12 connector, 4 DIs, 4 DIOs, -40 to 85°C operating temperature.
