Contact our U.S. based teamSpecifications
Product Information
MFR #
ioPAC 8600-BM005-T
Zoro #
G4580146
UPC #
-
Country of Origin
Taiwan, Province of China
Dimensions
Dimensions
5-slot version: 205.65 x 133.35 x 100 mm (8.1 x 5.25 x 3.94 in); 9-slot version: 324.8 x 133.35 x 100 mm (12.79 x 5.25 x 3.94 in)
Details
Input Voltage
24 to 110 VDC
Mounting
DIN rail (optional), wall (optional), rack (optional)
Storage temperature
-40 to 85°C (-40 to 185°F)
Rail Traffic
EN 50155 (essential compliance*), EN 50121-3-2, EN 50121-4; *Moxa defines "essential ; compliance" to include those EN 50155 requirements that make products ; more suitable for rolling stock railway applications; Note: Please check Moxa's website for the most up-to-date certification ; status.
EMI
FCC Part 15 Subpart B Class A, CISPR 22
Operating temperature
-40 to 75°C (-40 to 176°F)
EMS
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV; IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m; 1400 MHz to 2100 MHz: 3 V/m; 2100 MHz to 2700 MHz: 1 V/m; IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV; IEC 61000-4-5 Surge: Power: 2 kV (L-PE), 1 kV (L-L
Housing
Aluminum
Altitude
Up to 2000 m
Ambient Relative Humidity
5 to 95% (non-condensing)
EMC
EN 55022/24
Vibration
IEC 60068-2-6
Shock
IEC 60068-2-27
Safety
UL 61010
Description
ioPAC 8600 backplane module, 5 slots
