  11. Remote Ethernet I/O, 8Ai, 2Port Switch, -40 To 75 Deg.C
Moxa Remote Ethernet I/O, 8Ai, 2Port Switch, -40 To 75 Deg.C ioLogik E1240-T - main

Remote Ethernet I/O, 8Ai, 2Port Switch, -40 To 75 Deg.C

  • Mfr # ioLogik E1240-T

  • Zoro # G4571490

product price: $653.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Input Impedance
10M ohms (min.)
Time
474,053 hrs
Safety
UL 508
Accuracy
±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E1240-T
Zoro #
G4571490
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)

Details

Mounting
DIN rail or wall
Input Impedance
10M ohms (min.)
Time
474,053 hrs
Safety
UL 508
Accuracy
±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
Type
Differential input
Isolation
3k VDC or 2k Vrms
Ambient Relative Humidity
5 to 95% (non-condensing)
EMI
EN 55022; EN 61000-3-2; EN 61000-3-3; FCC Part 15, Subpart B, Class A
Resolution
16 bits
Analog Inputs
8 channels
Input Range
0 to 10 VDC, 0 to 20 mA, 4 to 20 mA
EMS
EN 55024, EN 61000-4-2, EN 61000-4-3; EN 61000-4-4, EN 61000-4-5, EN 61000-4-6; EN 61000-4-8, EN 61000-4-11
Protection
1.5 kV magnetic isolation
Built-in Resistor for Current Input
120 ohms
Storage temperature
-40 to 85°C (-40 to 185°F)
I/O Mode
Voltage / Current
Altitude
Up to 2000 m
Sampling Rate
All channels: 12 samples/sec; Per channel: 1.5 samples/sec; Only one channel enabled: 12 samples/sec
Freefall
IEC 60068-2-32
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Wiring
I/O cable max. 14 AWG
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, HTTP
Shock
IEC 60068-2-27
Database
Telcordia (Bellcore)
Ethernet
2 switched 10/100 Mbps RJ45 ports
Power Input
24 VDC nominal, 12 to 36 VDC
Vibration
IEC 60068-2-6
Hazardous Location
UL/cUL Class I Diision 2, ATEX Zone 2
Power Consumption
121 mA @ 24 VDC

Description

Remote Ethernet I/O, 8AI, 2-port Switch, -40 to 75°C
