  11. Remote Ethernet I/O, 8Di, 4 Source Do, 4 Source Dio, 2Port Switch
Moxa Remote Ethernet I/O, 8Di, 4 Source Do, 4 Source Dio, 2Port Switch ioLogik E1213 - main

Remote Ethernet I/O, 8Di, 4 Source Do, 4 Source Dio, 2Port Switch

  • Mfr # ioLogik E1213

  • Zoro # G4571414

product price: $347.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Voltage
15 to 30 VDC (12 or 9 VDC configurable by jumper on the 4 DO channels)
Safety
UL 508
Ambient Relative Humidity
5 to 95% (non-condensing)
Counter/Frequency
250 Hz, power off storage
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E1213
Zoro #
G4571414
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)
Pulse Wave Width/Frequency
1 ms/500 Hz

Details

Mounting
DIN rail or wall
Voltage
15 to 30 VDC (12 or 9 VDC configurable by jumper on the 4 DO channels)
Safety
UL 508
Ambient Relative Humidity
5 to 95% (non-condensing)
Counter/Frequency
250 Hz, power off storage
I/O Mode
DO or Pulse Output, DI or event counter
EMS
EN 55024, EN 61000-4-2, EN 61000-4-3; EN 61000-4-4, EN 61000-4-5, EN 61000-4-6; EN 61000-4-8, EN 61000-4-11
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Output Current Rating
1.5 A per channel
Sensor Type
NPN, PNP, and dry contact
Protection
1.5 kV magnetic isolation
Over-temperature Shutdown
175°C (typical), 150°C (min.)
Power Input
24 VDC nominal, 12 to 36 VDC
Dry Contact
On: short to GND; Off: open
Storage temperature
-40 to 85°C (-40 to 185°F)
Digital Input/Output (configurable by jumper)
4 channels
Over-Current Limit
1.5 A per channel @ 25°C
Altitude
Up to 2000 m
Digital Outputs
4 channels
Shock
IEC 60068-2-27
Power Consumption
130 mA typical @ 24 VDC
Isolation
3k VDC or 2k Vrms
I/O Type
Source
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, HTTP
Wet Contact (DI to COM)
On: 10 to 30 VDC; Off: 0 to 3 VDC
EMI
EN 55022; EN 61000-3-2; EN 61000-3-3; FCC Part 15, Subpart B, Class A
Wiring
I/O cable max. 14 AWG
Common Type
12 points per COM
Freefall
IEC 60068-2-32
Hazardous Location
UL/cUL Class I Diision 2, ATEX Zone 2
Ethernet
2 switched 10/100 Mbps RJ45 ports
Current
500 mA per channel
Vibration
IEC 60068-2-6
Digital Inputs
8 channels
Over-voltage Protection
41 VDC

Description

Remote Ethernet I/O, 8DI, 4 Source DO, 4 Source DIO, 2-port Switch
