  11. Remote Ethernet I/O W/ 4Ao, And 2Port Switch, -40 To 75 Degrees C
Moxa Remote Ethernet I/O W/ 4Ao, And 2Port Switch, -40 To 75 Degrees C ioLogik E1241-T - main

Remote Ethernet I/O W/ 4Ao, And 2Port Switch, -40 To 75 Degrees C

  • Mfr # ioLogik E1241-T

  • Zoro # G4573767

product price: $759.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Wiring
I/O cable max. 14 AWG
Shock
IEC 60068-2-27
Ethernet
2 switched 10/100 Mbps RJ45 ports
Hazardous Location
UL/cUL Class I Diision 2, ATEX Zone 2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E1241-T
Zoro #
G4573767
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)

Details

Mounting
DIN rail or wall
Wiring
I/O cable max. 14 AWG
Shock
IEC 60068-2-27
Ethernet
2 switched 10/100 Mbps RJ45 ports
Hazardous Location
UL/cUL Class I Diision 2, ATEX Zone 2
Output Range
0 to 10 VDC, 4 to 20 mA
Ambient Relative Humidity
5 to 95% (non-condensing)
Altitude
Up to 2000 m
Load Resistor
Internal register, 400 ohms
Isolation
3k VDC or 2k Vrms
Vibration
IEC 60068-2-6
Freefall
IEC 60068-2-32
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Resolution
12 bits
Voltage Output
10 mA (max.)
Power Input
24 VDC nominal, 12 to 36 VDC
Time
888,656 hrs
Protection
1.5 kV magnetic isolation
EMS
EN 55024, EN 61000-4-2, EN 61000-4-3; EN 61000-4-4, EN 61000-4-5, EN 61000-4-6; EN 61000-4-8, EN 61000-4-11
Analog Outputs
4 channels
Storage temperature
-40 to 85°C (-40 to 185°F)
Accuracy
±0.1% FSR @ 25°C; ±0.3% FSR @ -40 and 75°C
EMI
EN 55022; EN 61000-3-2; EN 61000-3-3; FCC Part 15, Subpart B, Class A
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, HTTP
Safety
UL 508
Database
Telcordia (Bellcore)
Power Consumption
194 mA @ 24 VDC

Description

Remote Ethernet I/O with 4AO, and 2-port Switch, -40 to 75°C
