  11. Smart Ethernet Remote I/O W/ Click And Go, 12 Dis, 8 Dos, Iologik E2210
Moxa Smart Ethernet Remote I/O W/ Click And Go, 12 Dis, 8 Dos, Iologik E2210 ioLogik E2210 - main

Smart Ethernet Remote I/O W/ Click And Go, 12 Dis, 8 Dos, Iologik E2210

  • Mfr # ioLogik E2210

  • Zoro # G4574257

product price: $438.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Time
213,673 hrs
Over-current Protection
2.6 A (4 channels @ 650 mA)
Ambient Relative Humidity
5 to 95% (non-condensing)
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ioLogik E2210
Zoro #
G4574257
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Time
213,673 hrs
Over-current Protection
2.6 A (4 channels @ 650 mA)
Ambient Relative Humidity
5 to 95% (non-condensing)
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
Digital Filtering Time Interval
Software Configurable
Safety
UL 508
Protection
1.5 kV magnetic isolation
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Baudrate
1200 to 115200 bps
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Type
Sink
Common Type
12 points per COM
Vibration
IEC 60068-2-6
Power Input
24 VDC nominal, 12 to 36 VDC
Ethernet
1 10/100 Mbps RJ45 port
Digital Outputs
8 channels
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
I/O Mode
DO or Pulse Output, DI or Event Counter
Over-temperature Shutdown
175°C (min.)
Dry Contact
On: short to GND; Off: open
Protocol
Modbus/RTU
Altitude
Up to 2000 m
Serial Line Protection
15 kV ESD for all signals
Storage temperature
-40 to 85°C (-40 to 185°F)
Freefall
IEC 60068-2-32
Power Consumption
203 mA @ 24 VDC
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Data Bits
8
Isolation
3k VDC or 2k Vrms
Parity
None
Pulse Output Frequency
1 kHz
Stop Bits
1
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Over-voltage Protection
45 VDC
Counter Frequency
900 Hz
Sensor Type
Wet Contact (NPN), Dry Contact
Digital Inputs
12 channels
Shock
IEC 60068-2-27
Wiring
I/O cable max. 14 AWG
Database
Telcordia (Bellcore)
Current Rating
200 mA per channel

Description

Smart Ethernet remote I/O with Click and Go, 12 DIs, 8 DOs
