  11. Smart Ethernet Remote I/O W/ Click And Go, 12 Dis, 8 Dos, Iologik E2210-T
Moxa Smart Ethernet Remote I/O W/ Click And Go, 12 Dis, 8 Dos, Iologik E2210-T ioLogik E2210-T - main

Smart Ethernet Remote I/O W/ Click And Go, 12 Dis, 8 Dos, Iologik E2210-T

  • Mfr # ioLogik E2210-T

  • Zoro # G4573715

product price: $587.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Digital Inputs
12 channels
Current Rating
200 mA per channel
Ethernet
1 10/100 Mbps RJ45 port
Over-temperature Shutdown
175°C (min.)
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
ioLogik E2210-T
Zoro #
G4573715
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Digital Inputs
12 channels
Current Rating
200 mA per channel
Ethernet
1 10/100 Mbps RJ45 port
Over-temperature Shutdown
175°C (min.)
Digital Outputs
8 channels
Common Type
12 points per COM
Ambient Relative Humidity
5 to 95% (non-condensing)
Over-current Protection
2.6 A (4 channels @ 650 mA)
Vibration
IEC 60068-2-6
Isolation
3k VDC or 2k Vrms
Serial Line Protection
15 kV ESD for all signals
Shock
IEC 60068-2-27
Baudrate
1200 to 115200 bps
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
Dry Contact
On: short to GND; Off: open
Pulse Output Frequency
1 kHz
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Protocol
Modbus/RTU
Time
213,673 hrs
I/O Mode
DO or Pulse Output, DI or Event Counter
Database
Telcordia (Bellcore)
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Freefall
IEC 60068-2-32
Over-voltage Protection
45 VDC
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Power Consumption
203 mA @ 24 VDC
Stop Bits
1
Protection
1.5 kV magnetic isolation
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Safety
UL 508
Storage temperature
-40 to 85°C (-40 to 185°F)
Parity
None
Sensor Type
Wet Contact (NPN), Dry Contact
Power Input
24 VDC nominal, 12 to 36 VDC
Type
Sink
Data Bits
8
Digital Filtering Time Interval
Software Configurable
Altitude
Up to 2000 m
Wiring
I/O cable max. 14 AWG
Counter Frequency
900 Hz

Description

Smart Ethernet remote I/O with Click and Go, 12 DIs, 8 DOs, -40 to 75°C
