Bearing, 10mm, 7610 N, Steel
Mfr # 5200SB
Zoro # G0261077
product price: $52.49
/eaKey Features
Contact Angle (Degree)
30 Degrees
Bore Dia.
10 mm
Outside Dia.
30 mm
Width
14.29 mm
Cage Material
Steel
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
5200SB
Zoro #
G0261077
UPC #
-
Country of Origin
Multiple
Dimensions
Bore Dia.
10 mm
Outside Dia.
30 mm
Width
14.29 mm
Overall Width
14.3 mm
Bore Diameter
10 mm
Housing Fillet Radius
0.64 mm
Outside Diameter
30 mm
Description
Angular Contact Ball Bearing, Bearing Industry Number 5200, Bore Diameter 10 mm, Cage Material Steel, Closure Open, Contact Angle 30 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Not Matched/Single Bearing, Maximum Speed 22,000 RPM, Maximum Temperature 125 Degrees C, Minimum Temperature -20 Degrees C, Number of Rows Two, Outside Diameter 30 mm, Overall Width 14.3 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 1
