Shop NATIONAL GUARD

Concealed Fastener Seal, Aluminum, 1/8 In.

  • Mfr # 172NDKB-36x84

  • Zoro # G1600186

product price:
$
118.99
/ea
Free Shipping & Returns

Key Features

For Use With
Doors
Overall Length
3 ft
Projection
5/16 in
Color
Dark Bronze
Product Type
Door Weatherstripping
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
172NDKB-36x84
Zoro #
G1600186
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
3 ft
Insert Size
1/8 in
Overall Height
5/16 in
Flange Width
3/4 in
Overall Width
1 in
Flange Thickness
0.31 in
Wire Rope Length
3 ft
Length
3 ft

Details

For Use With
Doors
Projection
5/16 in
Color
Dark Bronze
Item
Door Weatherstripping
Product Type
Door Weatherstripping
Insert Color
Black
Insert Material
EPDM
Flange Material
Aluminum
Mounting Type
Concealed Screw
Standards
ANSI/BHMA A156.22, ANSI/UL10B, ANSI/UL10C, ANSI/UL1784, ASTM E283, CAN/ULC-S104, NFPA 105, NFPA 252, NFPA 80
Includes
(2) 7 ft Strips, 3 ft Strip
Flange Finish
Dark Bronze
Material
Aluminum
Stays Flexible to
-20 Degrees F
Sold As
Set
Flange Color
Dark Bronze
UL Fire Rating
UL10B, UL10C
Green Environmental Attribute
Applicable to LEED Criteria
Green Certification or Other Recognition
Environmental Transparency Through EPD (Environmental Product Declaration), Health Product Declaration Collaborative
Temperature - Minimum
-81 Degrees F
Mounting Style
Screw-In
Temperature - Maximum
275 Degrees F
Flange Projection
5/16 in
Fire Rating
1 1/2 hr

Description

Concealed Fastener Seal, Overall Length 3 ft., Overall Width 13/16 In., Overall Height 5/16 In., Color Dark Bronze, Material Aluminum, Flange Material Aluminum, Flange Thickness 5/16 In., Insert Color Black, Insert Material Neoprene, Insert Size 1/8 In., Mounting Type Screw, Stays Flexible to -20 Degrees F, Projection 5/16 In., For Use With Doors, Sold As Roll, Standards ANSI/UL10C (Category H), CAN/ULC-S104, ANSI/UL10B, ANSI/UL1784, ANSI/BHMA A156.22
