  13. Weatherstrip, 3/16in., Vinyl, Gray
National Guard Weatherstrip, 3/16in., Vinyl, Gray 159MA-36x84 - main

Weatherstrip, 3/16in., Vinyl, Gray

  • Mfr # 159MA-36x84

  • Zoro # G1616161

product price: $160.99
/ea
Free Shipping & Returns

Key Features

For Use With
Doors
Overall Length
3 ft
Projection
5/8 in
Product Type
Weatherstripping
Insert Color
Gray
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
159MA-36x84
Zoro #
G1616161
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
3 ft
Insert Size
3/16 in
Overall Height
7 ft
Flange Height
1 1/4 in
Flange Thickness
0.063 in
Overall Width
1 1/4 in
Flange Width
1 1/8 in
Insert Size - Maximum
3/16 in

Details

For Use With
Doors
Projection
5/8 in
Item
Door Weatherstripping
Product Type
Weatherstripping
Insert Color
Gray
Insert Material
Vinyl
Flange Material
Aluminum
Mounting Type
Fastened by Screws
Standards
ANSI/BHMA A156.22, ASTM E2235, ASTM E283, ASTM E90, UL to ANSI, UL to ANSI and ANSI/UL1784, UL to CAN/ULC-S104 and ANSI Complies with NFPA 80 and NFPA 252
Sold As
Set
Fire Rated
2 hr
Flange Finish
Anodized
Includes
#6 x 3/4 in Stainless Steel SMS
Hardware
Included
Max. Door Gap
3/16 in
Stays Flexible to
10 Degrees F
Flange Color
Gray
Insert Type
Magnetic
UL Fire Rating
UL10B, UL10C
Green Environmental Attribute
Applicable to LEED Criteria
Green Certification or Other Recognition
Environmental Transparency Through EPD (Environmental Product Declaration), Health Product Declaration Collaborative
Temperature - Minimum
0 Degrees F
Temperature - Maximum
140 Degrees F
Includes Hardware
Hardware Included
Gap - Maximum
3/16 in
Flange Projection
1 1/4 in

Description

Door Weatherstripping, Insert Type Magnetic, Insert Material Vinyl, Insert Color Gray, Insert Size 3/16 in, Flange Material Aluminum, Flange Color Gray, Flange Finish Anodized, Flange Height 1 1/4 in, Flange Width 1 1/8 in, Flange Thickness 0.063 in, Overall Length 3 ft, Overall Width 1 1/4 in, Overall Height 7 ft, Stays Flexible to 10 Degrees F, Projection 5/8 in, Mounting Type Screw In, Max. Door Gap 3/16 in, Fire Rated 2 hr, For Use With Doors, Includes #6 x 3/4 in Stainless Steel SMS

Restrictions

Hazardous material
