Contact our U.S. based teamSpecifications
Product Information
MFR #
99616-3/4-142
Zoro #
G2527436
UPC #
-
Country of Origin
Taiwan, Province of China
Dimensions
Body Dia. (In.)
3/4
Overall Length (In.)
4
Insert Thickness (In.)
5/32
Shank Dia. (In.)
3/4
Shank Length (In.)
2.75
Details
Includes
Insert Screw And Torx Key
Cutting Capacity (In.)
Up to 0.728
Insert Shape
Square
For Use With
2TFC6, 2TFC7 And 2VMN1
Inscribed Circle (In.)
7/16
Number of Flutes
1
Lock
Screw
Item
Indexable NC Spot Drill
Included Angle (Deg.)
142
Type
Weldon Shank
Description
Indexable NC Spot Drill, Weldon Shank, Number of Pieces -, Number of Flutes 1, Included Angle (Deg.) 142, Cutting Capacity (In.) Up to 0.728, Body Dia. (In.) 3/4, Shank Dia. (In.) 3/4, Shank Length (In.) 2.75, Thread Size -, Overall Length (In.) 4, Screw Lock, For Use With 2TFC6, 2TFC7 And 2VMN1, Square Insert Shape, Inscribed Circle (In.) 7/16, Insert Thickness (In.) 5/32, Includes Insert Screw And Torx Key
