  5. Noctua NH-U12S 120mm CPU Cooler for Intel LGA2011-1156-1155-1150 & AMD Socket AM3 Plus -AM3-AM2 Plus -AM2-FM2-FM1

This item is Discontinued.

Noctua Noctua NH-U12S 120mm CPU Cooler for Intel LGA2011-1156-1155-1150 & AMD Socket AM3 Plus -AM3-AM2 Plus -AM2-FM2-FM1 NH-U12S

Noctua NH-U12S 120mm CPU Cooler for Intel LGA2011-1156-1155-1150 & AMD Socket AM3 Plus -AM3-AM2 Plus -AM2-FM2-FM1 (Discontinued)

  • Mfr # NH-U12S
  • Zoro # G304041966
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
NH-U12S
Zoro #
G304041966
UPC #
-
Country of Origin
China

Dimensions

Fan Diameter
0.98 in
Heatsink Height
6.22 in
Heatsink Width
4.92 in
Heatsink Depth
1.77 in

Details

Material
Copper Heat Pipe
Includes
Low-Noise Adapter (L.N.A.), NT-H1 high-grade Thermal Compound, SecuFirm2 Mounting Kit, Anti-vibration Pads and Fan-clips for Second NF-F12, Noctua Metal Case-Badge.
Color
Brown
Application
Processor
Air Flow
93.4 m³/h
Heatsink Material
Aluminum
Max. Airflow
411.2 gal/min
Item
Cooling Fan/Heatsink
Number of Fans
1
Fan Speed (Max)
1500 rpm
Compatibility
AMD Socket: AM2 PGA-940, AM2+ PGA-940, AM3 PGA-941, AM3+, FM1, FM2, FM2+; Intel Socket: B LGA-1366, H LGA-1156, H2 LGA-1155, H3 LGA-1150, R LGA-2011, T LGA-775
Fan Bearing Type
SSO2
Input Voltage
12V DC

Description

Specifications

  • Mfr Part Number: NH-U12S
  • Features:
    • Award-winning NH-U12 series
    • 100% RAM compatibility
    • Classic 120mm tower size for excellent overall compatibility
    • NF-F12 120mm Focused Flow fan
    • PWM support and Low-Noise Adaptor
    • SecuFirm2 mounting system
    • Compatibility with past and future sockets
    • NT-H1 thermal compound
  • Compatibility:
    • Intel: LGA1156/ 1155/ 1150, LGA2011 (Square ILM)
    • AMD: Socket AM3+/ AM3/ AM2+/ AM2/ FM1/ FM2 (backplate required)
  • Noctua NF-P12 PWM Fan:
    • Rotational Speed: 1500 RPM 10% (Max); 1200 RPM 10% (Max, w/ L.N.A.); 300 RPM (Min, PWM)
    • Air Flow: 93.4 m3/h (Max); 74.3 m3/h (Max, w/ L.N.A.)
    • Acoustical Noise: 22.4 dBA (Max); 18.6 dBA (Max, w/ L.N.A.)
    • Voltage Range: 12 V
    • Input Power: 0.6 W
    • Bearing Type: SSO2
    • MTBF: >150,000 hours
  • Material: Copper (base and heat-pipes), Aluminium (cooling fins), Soldered Joints & Nickel Plating
  • Fan Compatibility: 120.0 x 120.0 x 25.0 mm
  • Dimensions (WxDxH): 125.0 x 71.0 x 158.0 mm (w/ Fan), 125.0 x 45.0 x 158.0 mm (w/o Fan)
  • Weight: 755.0 g (w/ Fan), 580.0 g (w/o Fan)
  • Scope of Delivery:
    • NF-F12 PWM Premium Fan
    • Low-Noise Adapter (L.N.A.)
    • NT-H1 High-grade Thermal Compound
    • SecuFirm2 Mounting Kit
    • Anti-vibration Pads and Fan-clips for Second NF-F12
    • Noctua Metal Case-Badge
