Water Softener, 2" Pipe, Three Tank, 78" W

  • Mfr # PA132D-1

  • Zoro # G7342811


product price: $11,719.99
/ea
Item requires special delivery charges. A $130.00 per item surcharge will be applied.

Key Features

Max. Grain Capacity
132,000
Number of Brine Tanks
1
Pipe Size (In.)
2 in
Height (In.)
73 in
Service Flow Rate (GPM)
40
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PA132D-1
Zoro #
G7342811
UPC #
-
Country of Origin
United States

Dimensions

Pipe Size (In.)
2 in
Height (In.)
73 in
Width (In.)
78 in
Depth (In.)
24 in
Overall Height
72 1/2 in
Brine Tank Diameter
24 in
Manufacturer Warranty Length
1 yr Parts, 10 yr Resin Tank, 3 yr Electronics, 3 yr Salt Tank
Resin Tank Overall Height
58 in
Overall Depth
24 in
Brine Tank Height
50 in
Overall Width
58 in
Pipe Size
2 in
Resin Tank Diameter
17 in
Resin Tank Overall Width
17 in

Details

Max. Grain Capacity
132,000
Number of Brine Tanks
1
Service Flow Rate (GPM)
40
Item
Multi-Tank Water Softener
Distributor Type
Counter Current Regeneration
Salt Storage Capacity (Lb.)
1,000
Meter Range (GPM)
0 - 1000
Type
Demand Initiated Regeneration
Tank Type
Three Tank
Days Between Regeneration
Demand
Tank Material
Fiberglass
Grains Capacity at 10 lb/cu ft Salt Dosage
124,000
Tank Capacity
4 cu ft
Single Tank Maximum Resin Capacity
4 cu ft
Total Number of Tanks
3
Grains Capacity at 4 lb/cu ft Salt Dosage
72,000
Maximum Operating Temperature
100 Degrees F
Includes
2 in High Molecular Weight Plastic Valve
Standards
C US Listed, ISO 9001 Registered, NSF Certified
Salt Free
No
Minimum Operating Pressure
30 psi
Application
Hospitals, Hotels, Restaurants, Steam Boilers
Market
Commercial
Grains Capacity at 12 lb/cu ft Salt Dosage
132,000
Distributor Regeneration Type
Counter Current Regeneration
Brine Tank Capacity
1,000 lb
Features
Fully Programmable, High-Density Salt Storage Tank, Non-Volatile Memory, Safe 24V Electronics, Selectable for Parallel, Parallel Delayed, Alternating, and Peak Flow Demand, Self-Cleaning Upper and Lower Distributors, SPA Diagnostic Capabilities, Washed Quartz Underbedding, Water Usage is Metered by Turbine
Resin Tank Material
Fiberglass
Single Tank Minimum Flow Rate Scale
10 gpm
Demand Regeneration
Yes
Minimum Operating Temperature
35 Degrees F
Grains Capacity at 6 lb/cu ft Salt Dosage
96,000
Single Tank Maximum Grain Capacity
132,000
System Functions
Adjustable Backwash, Prevents Scale Buildup, Removes Iron, Water Conditioning
Single Tank Regeneration Water Used
166 gal
Single Tank Maximum Flow Rate Scale
40 gpm
Maximum Iron Reduction
5 ppm
Number of Resin Tanks
2
Corrosion Resistant
Yes
Grains Capacity at 8 lb/cu ft Salt Dosage
112,000
Pipe Connection Type
NPT
Maximum Operating Pressure
125 psi

Description

Multi-Tank Water Softener, Single Tank Maximum Grain Capacity 132,000, Brine Tank Capacity 1,000 lb, Total Number of Tanks 3, Number of Resin Tanks 2, Number of Brine Tanks 1, Brine Tank Depth Not Applicable, Brine Tank Diameter 24 in, Brine Tank Height 50 in, Brine Tank Width Not Applicable, Grains Capacity at 10 lb/cu ft Salt Dosage 124,000, Grains Capacity at 12 lb/cu ft Salt Dosage 132,000, Grains Capacity at 4 lb/cu ft Salt Dosage 72,000, Grains Capacity at 6 lb/cu ft Salt Dosage 96,000
