Flange Bearing, 2-Bolt, Ball, 1-1/4" Bore

  • Mfr # SUCFL207-20

  • Zoro # G2490135

product price:  $357.99
/ea
Free Shipping & Returns

Key Features

System of Measurement
Inch
Housing Type
Rhombus
Number of Mount Holes
2
Bearing Insert Type
Radial Ball
Shaft Locking Type
Set Screw
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SUCFL207-20
Zoro #
G2490135
UPC #
-
Country of Origin
Multiple

Dimensions

Bolt Size
M14
Bore Diameter
1-1/4 in
Mount Hole Center-to-Center Length
5-1/8 in
Overall Length
5-13/32 in
Overall Width
1-3/4 in
Overall Height
3-33/64 in
Flange Thickness
19/32 in
Dimension N
17.5 mm
Dimension G
15 mm
Dimension A
161 mm
Dimension S
16 mm
Dimension L
34 mm
Dimension B
90 mm
Dimension E
130 mm
Mounting Bolt Size
1/2, M14
Back Side to Center Width
0.748 in
Mount Hole Size
0.63 in
Mount Hole Center-to-Center Height
0 in
Wire Rope Length
5 13/32 in
Center Height
1 49/64 in
Inner Ring Width
1.69 in
Bolt Circle Diameter
3.54 in

Details

System of Measurement
Inch
Item
2 Bolt Flange Bearing
Housing Type
Rhombus
Number of Mount Holes
2
Bearing Insert Type
Radial Ball
Shaft Locking Type
Set Screw
Housing Material
Stainless Steel
Bearing Insert Material
Stainless Steel
Series
Corrosion Resistant with USDA-H1 Grease
Dynamic Load Capacity
4,510 lbf
Finish
Chrome
Temp. Range
-4 to 250 Degrees F
Static Load Capacity
15600 N
Bearing Lubrication
Relubricateable
Includes
(2) Set Screws
Closure
Double Sealed
Resistance Properties
Corrosion-Resistant
Minimum Temperature
-4 Degrees F
Housing Material Grade
304
Bore Type
Cylindrical
Seal Type
Contact
Included Bearing
SUC207-20
Lubrication Openings
Grease Fitting
Application
Agriculture, Automotive, Cosmetic/Pharmaceutical, Food and Beverage, Food Processing, Industrial Machinery, Machine Tools, Material Handling, Refinery/Petrochemical
Bearing Material Grade
440C
Housing Material Finish
Unfinished
Maximum Speed
3,700 RPM
Seal Material
Silicone
Rolling Element Rows
1
Lubricant Material
H-1 Food Grade Solid Lubricant
Maximum Temperature
212 Degrees F
Static Radial Load Capacity
3,507 lbf
Expansion Type
Fixed
Includes Bearing Cap
Bearing Cap Not Included
Standards
IP69K
Features
Cap Ready
For Environment
Food and Beverage, Washdown
Split Housing
Not Split
Maximum Misalignment Angle
2 Degrees
Internal Clearance
CN
Load Direction
Thrust, Radial
Number of Rows
1

Description

Flange Mount Bearing, Back Side to Center Width 0.748 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 1/4 in, Bore Type Cylindrical, Center Height 1 49/64 in, Closure Double Sealed, Expansion Type Fixed, For Environment Food and Beverage, Washdown, Housing Material Stainless Steel, Housing Type Rhombus, Included Bearing SUC207-20, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Speed 3,700 RPM, Maximum Temperature 212 Degrees F
