Pillow Block Bearing, Ball, 2-3/16" Bore
Mfr # SUCP211-35
Zoro # G2818636
product price:Â
$
715.99
/ea
Free Shipping & Returns
Key Features
System of Measurement
Inch
Shaft Locking Type
Set Screw
Housing Material
Stainless Steel
Bearing Material
52100 Chrome Steel
Bearing Insert Type
Ball
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- SUCP211-35
- Zoro #
- G2818636
- UPC #
- -
- Country of Origin
- Multiple
Dimensions
- Bore Diameter
- 2.188 in
- Center Height
- 2-1/2 in
- Mount Hole Center-to-Center Length
- 6-23/32 in
- Mount Hole Size
- 0.787 in x 0.984 in
- Overall Length
- 8.62 in
- Overall Width
- 2.362 in
- Overall Height
- 4.96 in
- Dimension H1
- 23 mm
- Dimension H2
- 126 mm
- Dimension A
- 60 mm
- Dimension S
- 22.2 mm
- Dimension N
- 20 mm
- Dimension J
- 171 mm
- Dimension L
- 219 mm
- Dimension H
- 63.5 mm
- Dimension B
- 55.6 mm
- Mounting Bolt Size
- 5/8, M16
- Base Width
- 2.362 in
- Base Height
- 0.905 in
- Inner Ring Width
- 2.189 in
- Wire Rope Length
- 8.622 in
Description
Pillow Block Bearing, Base Height 0.905 in, Base Width 2.362 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 2 3/16 in, Bore Type Cylindrical, Center Height 2 1/2 in, Closure Open, Expansion Type Fixed, Housing Material Stainless Steel, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Speed 2,400 RPM, Maximum Temperature 212 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 6 23/32 in, Mount Type Bolt-Through
