Temperature and Humidity Transmitter: -40°C to 85°C, Transmitter, Head Mount Mounting
Mfr # TX13
Zoro # G921908291
product price: $311.99
/ea
Free Shipping & Returns
Key Features
Input Voltage
10 to 30V DC
Series
TX
Manufacturers Warranty Length
5 yr
Features
Galvanically Isolated, Programmable Burnout with Sensor Fail Indicator, Pushbutton Configuration
Response Time
1 sec
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- TX13
- Zoro #
- G921908291
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Manufacturers Warranty Length
- 5 yr
- Overall Diameter
- 1.69 in
- Overall Height
- 0.83 in
Details
- Input Voltage
- 10 to 30V DC
- Series
- TX
- Features
- Galvanically Isolated, Programmable Burnout with Sensor Fail Indicator, Pushbutton Configuration
- Response Time
- 1 sec
- Humidity Measurement - Maximum
- 90 %
- Process Media Temperature Measurement - Maximum
- 85 Degrees C
- Compensated Temperature - Maximum
- 80 Degrees C
- Standards
- CE, RoHS, UKCA
- Electrical Connection
- Screw Terminals
- Process Media Temperature Measurement - Minimum
- -40 Degrees F
- Operating Temperature - Maximum
- 85 Degrees C
- Operating Temperature - Minimum
- -40 Degrees C
- Display Screen Type
- No Display
- Output Power
- 4 to 20mA
- Item
- Temperature and Humidity Transmitter
- Temperature Sensor
- Transmitter
- Humidity Measurement - Minimum
- 10 %
- Compensated Temperature - Minimum
- -40 Degrees C
- Temperature Accuracy
- +/-0.5 Degrees C
- Humidity Accuracy
- +/- 5 micron A
- Mounting Style
- Head Mount
Description
MINATURE T/C TEMP TRANSMITTER
