  11. DC Power Supply, 100/240V AC, 12V DC, 15 W, 1.2 A, DIN Rail
Omron DC Power Supply, 100/240V AC, 12V DC, 15 W, 1.2 A, DIN Rail S8VK-G01512 - main

DC Power Supply, 100/240V AC, 12V DC, 15 W, 1.2 A, DIN Rail

  • Mfr # S8VK-G01512

  • Zoro # G5512735

product price: $69.79
/ea

Key Features

Input Voltage
100/240V AC
Output Voltage - Nominal
12V DC
Output Power - Rated
15 W
Current - Output
1.2 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S8VK-G01512
Zoro #
G5512735
UPC #
-
Country of Origin
Indonesia

Dimensions

Overall Height
22 mm
Overall Width
90 mm
Overall Depth
90 mm
Height
90 mm
Width
22 mm
Depth
90 mm
Wire Size - Maximum
12 AWG
Wire Size - Minimum
24 AWG

Details

Item
DC Power Supply
Input Voltage
100/240V AC
Output Voltage - Nominal
12V DC
Output Power - Rated
15 W
Current - Output
1.2 A
Mounting
DIN Rail
Housing Material
Plastic
Phase
Single
Power Supply Style
Switching
Case Material
Plastic Case
Phase - Electrical
Single
Features
It Also Saves Time And Reduces Costs Thanks To The Minimal Wiring Requirements And Easy One-Handed Mounting Provided By The Enhanced Din-Rail Mounting Clip, More Compact And Easier To Use, The S8VK Series Not Only Offers Greater Flexibility When Designing Machines
Hold Up Time
29 msec
Output Voltage
12V DC
Power Rating
15W
Hz
50/60 Hz
Standards
CE, CSA C22.2 No. 107.1/62368-1, cULus, cURus, EN50178, EN61558-2-16, EN62368-1, Lloyd's Standards EN60204-1 PELV, UL 508/62368-1
Output Amps
1.2A
Style
Switching
Peak Amps
1.44
Series
S8VK-G
Status Indicator
Green LED
Output Noise
50mV
Operating Temp. Range
-40 to 158°F
IP Rating
IP20
Input Frequency - Nominal
50/60 Hz
Current - Inrush
32 A
Current - Peak
1.44 A
Wire Connection Type
Screw Terminals
Special Features
Automatic Reset, LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Series Operation
Start Up Time - Maximum
580 msec
Mean Time Between Failures (MTBF)
135,000 hr
Manufacturer Warranty
3 yr
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
158 Degrees F

Description

DC Power Supply, Input Voltage 100 to 240V AC, Output Voltage 12V DC, Power Rating 15W, Output Amps 1.2, Mounting DIN Rail, Switching, Case Material Plastic Case, Height 90 mm, Width 22 mm, Depth 90 mm, Series S8VK-G, Hz 50 to 60 Hz, Phase - Electrical Single, Peak Amps 1.44, IP Rating IP20, Output Noise 50mV, Hold Up Time 29 msec, Status Indicator Green LED
