  11. DC Power Supply, 100/240V AC, 12V DC, 30 W, 2.5 A, DIN Rail
Omron DC Power Supply, 100/240V AC, 12V DC, 30 W, 2.5 A, DIN Rail S8VK-G03012 - main

DC Power Supply, 100/240V AC, 12V DC, 30 W, 2.5 A, DIN Rail

  • Mfr # S8VK-G03012

  • Zoro # G8550814

product price: $99.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
100/240V AC
Output Voltage - Nominal
12V DC
Output Power - Rated
30 W
Current - Output
2.5 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S8VK-G03012
Zoro #
G8550814
UPC #
-
Country of Origin
Indonesia

Dimensions

Overall Height
32 mm
Overall Width
90 mm
Overall Depth
90 mm
Height
90 mm
Depth
90 mm
Width
32 mm
Wire Size - Maximum
12 AWG
Wire Size - Minimum
24 AWG

Details

Item
DC Power Supply
Input Voltage
100/240V AC
Output Voltage - Nominal
12V DC
Output Power - Rated
30 W
Current - Output
2.5 A
Mounting
DIN Rail
Housing Material
Plastic
Phase
Single
Power Supply Style
Switching
Style
Switching
Power Rating
30W
Features
It Also Saves Time And Reduces Costs Thanks To The Minimal Wiring Requirements And Easy One-Handed Mounting Provided By The Enhanced Din-Rail Mounting Clip, More Compact And Easier To Use, The S8VK Series Not Only Offers Greater Flexibility When Designing Machines
Hold Up Time
36 msec
Case Material
Plastic Case
Output Voltage
12V DC
Standards
CE, CSA C22.2 No. 107.1/62368-1, cULus, cURus, EN50178, EN61558-2-16, EN62368-1, Lloyd's Standards EN60204-1 PELV, UL 508/62368-1
Operating Temp. Range
-40 to 158°F
Output Amps
2.5A
Phase - Electrical
Single
Series
S8VK-G
Peak Amps
3
Hz
50/60 Hz
Output Noise
30mV
Status Indicator
Green LED
IP Rating
IP20
Current - Inrush
32 A
Special Features
Automatic Reset, LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Series Operation
Wire Connection Type
Screw Terminals
Manufacturer Warranty
3 yr
Operating Temperature - Maximum
158 Degrees F
Current - Peak
3 A
Start Up Time - Maximum
600 msec
Operating Temperature - Minimum
-40 Degrees F
Mean Time Between Failures (MTBF)
135,000 hr
Input Frequency - Nominal
50/60 Hz

Description

DC Power Supply, Input Voltage 100 to 240V AC, Output Voltage 12V DC, Power Rating 30W, Output Amps 2.5, Mounting DIN Rail, Switching, Case Material Plastic Case, Height 90 mm, Width 32 mm, Depth 90 mm, Series S8VK-G, Hz 50 to 60 Hz, Phase - Electrical Single, Peak Amps 3, IP Rating IP20, Output Noise 30mV, Hold Up Time 36 msec, Status Indicator Green LED
