  11. DC Power Supply, 100/240V AC, 5V DC, 15 W, 3 A, DIN Rail
Omron DC Power Supply, 100/240V AC, 5V DC, 15 W, 3 A, DIN Rail S8VK-G01505 - main

DC Power Supply, 100/240V AC, 5V DC, 15 W, 3 A, DIN Rail

  • Mfr # S8VK-G01505

  • Zoro # G5821164

product price: $74.79
/ea

Key Features

Input Voltage
100/240V AC
Output Voltage - Nominal
5V DC
Output Power - Rated
15 W
Current - Output
3 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S8VK-G01505
Zoro #
G5821164
UPC #
-
Country of Origin
Indonesia

Dimensions

Overall Height
22 mm
Overall Width
90 mm
Overall Depth
90 mm
Depth
90 mm
Height
90 mm
Width
22 mm
Wire Size - Maximum
12 AWG
Wire Size - Minimum
24 AWG

Details

Item
DC Power Supply
Input Voltage
100/240V AC
Output Voltage - Nominal
5V DC
Output Power - Rated
15 W
Current - Output
3 A
Mounting
DIN Rail
Housing Material
Plastic
Phase
Single
Power Supply Style
Switching
Status Indicator
Green LED
Series
S8VK-G
Hold Up Time
28 msec
Operating Temp. Range
-40 to 158°F
Phase - Electrical
Single
Peak Amps
3.6
Style
Switching
Standards
CE, CSA C22.2 No. 107.1/62368-1, cULus, cURus, EN50178, EN61558-2-16, EN62368-1, Lloyd's Standards EN60204-1 PELV, UL 508/62368-1
Features
It Also Saves Time And Reduces Costs Thanks To The Minimal Wiring Requirements And Easy One-Handed Mounting Provided By The Enhanced Din-Rail Mounting Clip, More Compact And Easier To Use, The S8VK Series Not Only Offers Greater Flexibility When Designing Machines
Case Material
Plastic Case
Power Rating
15W
Output Amps
3A
Output Noise
60mV
Output Voltage
5V DC
Hz
50/60 Hz
IP Rating
IP20
Operating Temperature - Minimum
-40 Degrees F
Mean Time Between Failures (MTBF)
135,000 hr
Operating Temperature - Maximum
158 Degrees F
Wire Connection Type
Screw Terminals
Input Frequency - Nominal
50/60 Hz
Start Up Time - Maximum
600 msec
Manufacturer Warranty
3 yr
Current - Inrush
32 A
Current - Peak
3.6 A
Special Features
Automatic Reset, LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Series Operation

Description

DC Power Supply, Input Voltage 100 to 240V AC, Output Voltage 5V DC, Power Rating 15W, Output Amps 3, Mounting DIN Rail, Switching, Case Material Plastic Case, Height 90 mm, Width 22 mm, Depth 90 mm, Series S8VK-G, Hz 50 to 60 Hz, Phase - Electrical Single, Peak Amps 3.6, IP Rating IP20, Output Noise 60mV, Hold Up Time 28 msec, Status Indicator Green LED
