  11. Power Supply, 100/240V AC, 24V DC, 120 W, 5 A, DIN Rail
No Product Image Available

Power Supply, 100/240V AC, 24V DC, 120 W, 5 A, DIN Rail

  • Mfr # S8VK-X12024A-EIP

  • Zoro # G008273816

product price: $633.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
100/240V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
120 W
Current - Output
5 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S8VK-X12024A-EIP
Zoro #
G008273816
UPC #
4549734172721
Country of Origin
China

Dimensions

Overall Height
55 mm
Overall Width
94.7 mm
Overall Depth
92.3 mm
Height
94.7 mm
Depth
92.3 mm
Width
55 mm
Wire Size - Maximum
14 AWG
Wire Size - Minimum
18 AWG

Details

Item
Power Supply
Input Voltage
100/240V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
120 W
Current - Output
5 A
Mounting
DIN Rail
Phase
Single
Power Supply Style
Switching
Phase - Electrical
Single
Output Noise
150 mV @ 20 MHz
Style
Switching
Features
Power Boost Function at 150% (240 and 480 W), Product Replacement Time, Output Voltage, Output Current, and More are Acquired on the Network and can be Managed all at Once, Product Status can be Checked On-Site Using the Indication Monitor, Side-By-Side Mounting Possible (upto 55 Degrees C), UL Class 2 Conformance (90 W or Less)
Status Indicator
Green (Output), Red (Alarm)
Output Amps
5A
Hold Up Time
35 msec @ 115 V AC, 35 msec @ 230 V AC
Output Voltage
24V DC
IP Rating
IP20
Standards
EN/IEC 60529
Peak Amps
6 A
Power Rating
120W
Series
S8VK-X
Operating Temp. Range
-40 to 70°C
Hz
50/60 Hz
Operating Temperature - Minimum
-40 Degrees F
Current - Inrush
32 A
Special Features
Alarm Indication, LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Peak-Hold Current Indication, Series Operation, Total Run Time Monitor
Mean Time Between Failures (MTBF)
110,000 hr
Maximum Efficiency @ 115V AC
90 %
Manufacturer Warranty
5 yr
Wire Connection Type
Push In
Input Frequency - Nominal
50/60 Hz
Start Up Time - Maximum
1,000 msec
Operating Temperature - Maximum
158 Degrees F
Current - Peak
6 A
Maximum Efficiency @ 230V AC
92 %

Description

DC Power Supply, Input Voltage 100 to 240V AC, Output Voltage 24 V DC, Power Rating 120 W, Output Amps 5 A, Mounting DIN Rail, Switching, Height 94.7 mm, Width 55 mm, Depth 92.3 mm, Series S8VK-X, Hz 50 Hz/60 Hz, Phase - Electrical Single, Peak Amps 6 A, IP Rating IP20, Output Noise 150 mV @ 20 MHz, Hold Up Time 35 msec @ 115 V AC, 35 msec @ 230 V AC, Status Indicator Green (Output), Red (Alarm)
