  6. Switching Power Supply, 265/300V AC; 85/264V AC; 90/350V DC, 24V DC, 480 W, 20 A, DIN Rail
Omron Switching Power Supply, 265/300V AC; 85/264V AC; 90/350V DC, 24V DC, 480 W, 20 A, DIN Rail S8VK-S48024 - main

Switching Power Supply, 265/300V AC; 85/264V AC; 90/350V DC, 24V DC, 480 W, 20 A, DIN Rail

  • Mfr # S8VK-S48024

  • Zoro # G810080886

product price:  $502.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
265/300V AC; 85/264V AC; 90/350V DC
Output Voltage - Nominal
24V DC
Output Power - Rated
480 W
Current - Output
20 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
S8VK-S48024
Zoro #
G810080886
UPC #
4548583761148
Country of Origin
China

Dimensions

Overall Height
60 mm
Overall Width
124.6 mm
Overall Depth
122.2 mm
Width
60 mm
Height
124.6 mm
Depth
122.2 mm
Wire Size - Minimum
20 AWG
Wire Size - Maximum
10 AWG

Details

Item
Switching Power Supply
Input Voltage
265/300V AC; 85/264V AC; 90/350V DC
Output Voltage - Nominal
24V DC
Output Power - Rated
480 W
Current - Output
20 A
Mounting
DIN Rail
Phase
Single
Power Supply Style
Switching
Hz
50/60 Hz
Hold Up Time
30 msec
Status Indicator
Green LED
Phase - Electrical
Single
Features
Five Years Warranty, Low-Voltage Detection Output, Power Boost Function at 150%
Output Noise
21.6 to 28 mV
Output Amps
20A
Output Voltage
24V DC
Operating Temp. Range
-40 to 70°C
IP Rating
IP20
Style
Switching
Series
S8VK-S
Standards
EN/IEC 60529
Power Rating
480W
Maximum Efficiency @ 115V AC
91 %
Current - Peak
30 A
Mean Time Between Failures (MTBF)
330,000 hr
Input Frequency - Nominal
50/60 Hz
Operating Temperature - Minimum
-40 Degrees F
Wire Connection Type
Push In
Manufacturer Warranty
5 yr
Operating Temperature - Maximum
158 Degrees F
Start Up Time - Maximum
1,000 msec
Current - Inrush
32 A
Special Features
LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Series Operation, Undervoltage Alarm Indication
Maximum Efficiency @ 230V AC
93 %

Description

Switching Power Supply, Input Voltage 100 to 240V AC, Output Voltage 24 V DC, Power Rating 480 W, Output Amps 20 A, Mounting DIN Rail, Switching, Height 124.6 mm, Width 60 mm, Depth 122.2 mm, Series S8VK-S, Hz 50 Hz/60 Hz, Phase - Electrical Single, IP Rating IP20, Output Noise 21.6 to 28 mV, Status Indicator Green LED, Features Five Years Warranty, Low-Voltage Detection Output, Power Boost Function at 150 Percent, Operating Temp. Range -40 Degrees to 70 Degrees C, Standards EN/IEC 60529
