  9. Milling Insert, Parallelogram, Q, XP3225
Osg Milling Insert, Parallelogram, Q, XP3225 7820049 - main

Milling Insert, Parallelogram, Q, XP3225

  • Mfr # 7820049

  • Zoro # G7768489

product price: $61.19
/ea

Key Features

Steel (P) Compatibility
Yes
Workpiece Compatibility
Nonferrous (N), Stainless (M), Super Alloy (S)
Insert Shape
Parallelogram
Nose Radius
3.5mm
Insert Application
Finishing
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
7820049
Zoro #
G7768489
UPC #
-
Country of Origin
Japan

Dimensions

Nose Radius
3.5mm
Insert Thickness
2.00mm
Insert Size
070
Radius
220 Degrees
Cutting Edge Length
7.00mm
Width
5.50mm
Corner Radius
3.50mm
Thickness
2.00 mm

Details

Steel (P) Compatibility
Yes
Workpiece Compatibility
Nonferrous (N), Stainless (M), Super Alloy (S)
Insert Shape
Parallelogram
Insert Application
Finishing
Non Ferrous (N) Compatibility
Yes
Insert Style
PFB
ANSI Number
PFB070-Q
For Use With
Indexable Ballnose End Mills
No. of Edges
1
Mounting Style
Screw
Stainless (M) Compatibility
Yes
Coating
Cr
Cast Iron (K) Compatibility
No
Super Alloy (S) Compatibility
Yes
Insert Material
Carbide
Item
Ball Nose Milling Insert
ISO Number
PFB070-Q
Inscribed Circle
7.00mm
Cutting Direction
Right Hand
Hardened (H) Compatibility
No
Grade
XP3225
Chip-Breaker
Yes
Series
78PFB
Coating Process
PVD
Primary Material Application ISO Code
M, N, P
Material - Machining
Carbide
Measurement System
Metric
Secondary Material Application
Nickel, Titanium
For Toolholder
PFB-R100SF6, PFB-R120SF6, PFB-R160SF8, PFB-R200SF10, PFB-R250SF12, PFB-R300SF16
Secondary Material Application ISO Code
S
Cutting Application
Finishing
Number of Cutting Edges
1
Shape
Ball Nose
Chip-Breaker Code
Q
Manufacturer Grade
XP3225
Primary Material Application
Aluminum, Stainless Steel, Steel, Tool And Die Steel
Features
Composed of a Tough Carbide Material with an Excellent General Purpose Coating

Description

Ball Nose Milling Insert, Inscribed Circle 7.00mm, Q
