Thread Forming Tap, 7/16"-14, Modified Bottoming, TiCN, 0 Flutes

  • Mfr # 1625076148

  • Zoro # G9242055

product price:  $96.29
/ea

Key Features

Tap Thread Size
7/16"-14
Tap Chamfer
Modified Bottoming
Tap Finish
TiCN
Number of Flutes
0
Tap Style
Thread Forming
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
1625076148
Zoro #
G9242055
UPC #
-
Country of Origin
Japan

Dimensions

Tap Thread Size
7/16"-14
Pitch Diameter Limit
H8
Thread Length
1-7/16"
Overall Length
3-15/16"
Shank Dia.
0.242"
Tap Dimension Type
Inch
Tap Size
7/16"
65% Thread Drill Size
10.30 mm
Tap Length Standard
DIN
Thread Size
7/16"-14
75% Thread Drill Size
10.20 mm
55% Thread Drill Size
10.40 mm
Shank Length
2 7/32 in
Square Size
0.2420 in
Square Width
0.24 in
Neck Length
1.69 in
Square Length
0.406 in
Shank Diameter
0.322 in

Details

Item
Thread Forming Tap
Tap Chamfer
Modified Bottoming
Tap Finish
TiCN
Number of Flutes
0
Tap Style
Thread Forming
List Number
16250
Tap Grouping
Tap
Number of Pieces
1
Tap Material
Cobalt
Thread Direction
Right Hand
Tap Thread Type
UNC
Standards
DIN
Cutting Direction - Machining
Right Hand
Series
16250
Primary Material Application
Aluminum, Brass, Bronze, Copper, Hardened Steel, Stainless Steel, Steel, Tool and Die Steel
Secondary Material Application
Nickel, Titanium
Material Grade - Machining
16250
Coolant Fed
Non-Coolant Through
Spiral Direction
Neutral
Extended Neck
Yes
Class of Fit
2B-3B
Features
Produces No Chips
Secondary Material Application ISO Code
H, S
Thread Limit
H8
Thread Standard
UNC
Threads per Inch
14
Primary Material Application ISO Code
H, M, N, P
Tap Shank Standard
ANSI
Helix Angle
0 Degrees
Tap Application
Blind Hole, Through Hole
Shank Type
Square

Description

Thread Forming Tap, Thread Size 7/16 In.-14, UNC, Overall Length 3.94 in, Cobalt, V, Right Hand, Thread Length 0.71 in, 75 Percent Thread Drill Size 10.20 mm, Thread Limit H8, Class of Fit 2B-3B, Tap Length Standard DIN
