Thread Forming Tap, M5-0.80, Bottoming, TiCN, 0 Flutes

Osg Thread Forming Tap,  M5-0.80,  Bottoming,  TiCN,  0 Flutes 1410108708
Tap to zoom
Hover or click to zoom
Feedback Help us improve our product images
$17.43
  • Thread Direction: Right Hand
  • Item: Thread Forming Tap
  • Pitch Diameter Limit: D8
See full product details
Orders over $75 ship free.
Total: $17.43

Osg #1410108708 Specifications

  • Thread Direction: Right Hand
  • Item: Thread Forming Tap
  • Pitch Diameter Limit: D8
  • Overall Length: 60.00mm
  • Tap Style: Thread Forming
  • Tap Grouping: Tap
  • Tap Thread Type: Metric Coarse
  • Number of Flutes: 0
  • List Number: 14101
  • Tap Dimension Type: Metric
  • Standards: ANSI
  • Shank Dia.: 3.93mm
  • Tap Chamfer: Bottoming
  • Number of Pieces: 1
  • Tap Material: Cobalt
  • Tap Size: M5
  • Tap Finish: TiCN
  • Tap Thread Size: M5-0.80
  • Thread Length: 22.00mm
  • Series: 14101
  • Cutting Direction - Machining: Right Hand
  • Shank Length: 37.40 mm
  • Spiral Direction: Neutral
  • Extended Neck: No
  • 55% Thread Drill Size: #13
  • Features: For a Wide Range of Materials, Forming Tap
  • Thread Size: M5x0.8
  • Material Grade - Machining: 14101
  • Thread Standard: Metric Coarse
  • Square Size: 3.86 mm
  • 65% Thread Drill Size: 4.65 mm
  • Primary Material Application ISO Code: N, P
  • Secondary Material Application ISO Code: H, M, P
  • Thread Pitch: 0.80mm
  • Coolant Fed: Non-Coolant Through
  • Primary Material Application: Aluminum, Brass, Bronze, Copper, Steel
  • Secondary Material Application: Hardened Steel, Stainless Steel, Steel
  • Thread Limit: D8
  • 75% Thread Drill Size: 4.60 mm
  • Country of Origin (subject to change): Japan
Feedback Help us improve our product information

Description

Thread Forming Tap, Thread Size M5x0.8, Metric Coarse, Overall Length 60.00 mm, Cobalt, TiCN, Right Hand, Thread Length 10.00 mm, 75 Percent Thread Drill Size 4.60 mm, Thread Limit D8
