  9. Cat 5E Punchdown Jack Module - Green (10 Pack), 10PK
Panduit Cat 5E Punchdown Jack Module - Green (10 Pack), 10PK NKP5E88MGR - main

Cat 5E Punchdown Jack Module - Green (10 Pack), 10PK

  • Mfr # NKP5E88MGR

  • Zoro # G104858382

product price: $71.69
/pk 10, $7.17/ea

Key Features

Color
Green
Connector Type
Jack Module
Width
0.65 in
Type
Jack Module
Depth
1.16 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
NKP5E88MGR
Zoro #
G104858382
UPC #
7498310694
Country of Origin
Costa Rica

Dimensions

Width
0.65 in
Depth
1.16 in
Height
0.9 in
Overall Height
0.9
Overall Width
0.65
Overall Length
1.16 in
Overall Height (In.)
0.9
Overall Depth (In.)
1.16
Overall Length (In.)
1.16
Overall Width (In.)
0.65

Details

Color
Green
Connector Type
Jack Module
Type
Jack Module
Termination Type
Punchdown
Standards
Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
Note
Punchdown style termination
Shield Type
Unshielded (UTP)
Maximum Storage Temperature (°C)
75
Maximum Operating Temperature (°C)
75
Wiring Scheme
T568A/T568B
Standards Met
Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
Performance Level
Category 5e
Body Material
Polycarbonate
Minimum Storage Temperature (°C)
-40
Minimum Operating Temperature (°C)
-10
Contact Material
Plated Phosphor Bronze
Module Type
Keystone
Termination Style
Punchdown
Product Type
Jack Module
Product Class
Copper Systems
Min Operating Temperature
-10 degrees celsius
Max Operating Temperature
65 degrees celsius

Description

The NetKey Cat 5e UTP RJ45 Punchdown Keystone Jack Module is designed to terminate 4-pair, 22-26 AWG twisted pair cable. Each module is 100% factory tested to exceed industry standard performance requirements. Contacts are plated with 50 microinches of gold for superior performance. Jacks are individually serialized, and are compatible with keystone interfaces such as NetKey Faceplates, Modular Patch Panels, and Surface Mount Boxes. The module is green.

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
