Cat 6 Punchdown Jack Module (25 Pack), 25PK
- Mfr # NK688MGR-Q
- Zoro # G804859085
product price:Â
$
204.99
/pk 25, $8.20/ea
Free Shipping & Returns
Key Features
Color
Green
Termination Type
Punchdown
Height
0.9 in
Width
0.65 in
Connector Type
Jack Module
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- NK688MGR-Q
- Zoro #
- G804859085
- UPC #
- 7498399715
- Country of Origin
- United States
- Color
- Green
- Termination Type
- Punchdown
- Connector Type
- Jack Module
- Type
- Jack Module
- Standards
- Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
- Shield Type
- Unshielded (UTP)
- Body Material
- Polycarbonate
- Maximum Operating Temperature (°C)
- 75
- Minimum Storage Temperature (°C)
- -40
- Maximum Storage Temperature (°C)
- 75
- Wiring Scheme
- T568A/T568B
- Note
- Punchdown style termination; convenience pack of 25
- Minimum Operating Temperature (°C)
- -10
- Contact Material
- Plated Phosphor Bronze
- Termination Style
- Punchdown
- Module Type
- Keystone
- Product Type
- Jack Module
- Standards Met
- Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
- Performance Level
- Category 6
- Min Operating Temperature
- -10 degrees celsius
- Product Class
- Copper Systems
- Max Operating Temperature
- 65 degrees celsius
Description
The NetKey Cat 6 UTP RJ45 Punchdown Keystone Jack Module is designed to terminate 4-pair, 22-26 AWG twisted pair cable. Each module is 100% factory tested to exceed industry standard performance requirements. Contacts are plated with 50 microinches of gold for superior performance. Jacks are individually serialized, and are compatible with keystone interfaces such as NetKey Faceplates, Modular Patch Panels, and Surface Mount Boxes. The module is green and includes 25 per package.
