  11. Lug Compression Connector, 1/0 AWG Max, 3/8 in Stud, Long Barrel, Copper, Pink
Panduit Lug Compression Connector, 1/0 AWG Max, 3/8 in Stud, Long Barrel, Copper, Pink LCC1/0-38D-X - main

Lug Compression Connector, 1/0 AWG Max, 3/8 in Stud, Long Barrel, Copper, Pink

  • Mfr # LCC1/0-38D-X

  • Zoro # G0416009

product price: $14.55
/ea

Key Features

For Wire Size
1/0 AWG
For Conductor Material
Copper
For Stud Size
3/8 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCC1/0-38D-X
Zoro #
G0416009
UPC #
7498338271
Country of Origin
Mexico

Dimensions

For Wire Size
1/0 AWG
For Stud Size
3/8 in
Barrel Size
Long
Tongue Width
0.76 in
Cable Size
1/0 AWG
Length
3.69"
Width
0.76"
Length (mm)
93.7
Tongue Thickness (mm)
3
Stud Hole Size (In.)
44993
Barrel Length (In.)
1.44
Tongue Width In. (mm)
0.76 (19.3)
Tongue Thickness In. (mm)
0.12 (3)
Stud Hole Size In. (mm)
3/8 (9.5)
Wire Strip Length (In.)
1.5
Wire Strip Length (mm)
38.1
Length In (mm)
3.69 (93.7)
Code Conductor Size
1/0 AWG Code
Conductor Size
1/0 AWG Code
Wire Strip Length In. (mm)
1.5 (38.1)
Tongue Thickness
0.12
Tongue Width (In.)
0.76
Barrel Length (mm)
36.6
Length (In.)
3.69
Copper Conductor Size
1/0 AWG
Barrel Length In. (mm)
1.44 (36.6)
Stud Hole Size (mm)
9.5
Tongue Width (mm)
19.3

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
12
Color Code
Pink
Standards
CSA Certified: C22.2 No. 65-13
Connector Type
Long Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Stud Hole Spacing (mm)
25.4
Tested by Telcordia-Meets NEBS Level 3
Yes
Tin-Plating Meets ASTM B545-97, Class C
320µ in (8µ m)
Barrel Style
Standard
Panduit Color Code
Pink
Tongue Type
Standard
Angle
Straight
Conductor Material
Copper
CSA Certified
C22.2 No. 65-13
Burndy Die Index No.
12
UL and CSA Voltage Rating
35kV
Stud Hole Spacing In. (mm)
1 (25.4)
Stud Hole Spacing (In.)
1
UL and CSA Temperature Rating
90°
Clearance
0.47
T&B Die Index No.
42
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Type
Terminal Connector

Description

Lug,Cu,2 Hole,1/0 Awg,3/8 Stud,1
