Shop PANDUIT

Lug Compression Connector, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black

  • Mfr # LCAX2/0-12-X

  • Zoro # G0773731

product price:  $9.25
/ea

Key Features

For Wire Size
2/0 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAX2/0-12-X
Zoro #
G0773731
UPC #
7498343542
Country of Origin
Mexico

Dimensions

For Wire Size
2/0 AWG
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
0.96 in
Length
2.28 in
Cable Size
2/0 AWG
Width
0.96 in
Overall Length
2.28 in
Wire Strip Length (mm)
22.2
Inside Diameter (mm)
12.95
Outer Diameter (In.)
0.64
Copper Code Conductor Size (AWG)
36557
Stud Hole Size (mm)
12.7
Wire Strip Length (In.)
45115
Tongue Width (mm)
24.4
Class I Copper Flex Conductor Size (AWG)
36557
Tongue Thickness (In.)
0.13
Barrel Length (mm)
21.1
Class H Copper Flex Conductor Size (AWG)
36557
Stud Hole Size (In.)
1 to 2
Barrel Length (In.)
0.83
Tongue Width (In.)
0.96
Outer Diameter (mm)
16.25
Class M Copper Flex Conductor Size (AWG)
36557
Tongue Thickness (mm)
3.3
DLO Copper Flex Conductor Size (AWG)
36557
Overall Length (mm)
58.4
Class G Copper Flex Conductor Size (AWG)
36557
Overall Length (In.)
2.28
Class K Copper Flex Conductor Size (AWG)
36557
Inside Diameter (In.)
0.51

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
13
Color Code
Black
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Features
Corrosion Resistant, Angled Connector
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
Lug Type
1 Stud Hole Lug
Panduit Die Index Number
P45
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
13
Base Material
Copper
T & B Die Index Number
13
Maximum Voltage (kV)
35
Connector Plating
Tin
Product Name
Terminal Connector
Connector Details
1 x Terminal
Product Material
Copper
Product Class
Lugs, Splices, Split Bolts & Accessories

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
