  11. Lug Compression Connector, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange
Panduit Lug Compression Connector, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange LCAX3/0-12-X - main

Lug Compression Connector, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange

  • Mfr # LCAX3/0-12-X

  • Zoro # G0773923

product price: $10.45
/ea

Key Features

Cable Size
3/0 AWG
Connector Type
Standard Barrel
Width
1.06"
Material
Copper
Length
2.4"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX3/0-12-X
Zoro #
G0773923
UPC #
7498343554
Country of Origin
Mexico

Dimensions

Cable Size
3/0 AWG
Width
1.06"
Length
2.4"
Overall Length
2.4 in
DLO Copper Flex Conductor Size (AWG)
36586
Class M Copper Flex Conductor Size (AWG)
36586
Tongue Width (In.)
1.06
Stud Hole Size (In.)
1 to 2
Overall Length (In.)
2.4
Class K Copper Flex Conductor Size (AWG)
36586
Barrel Length (mm)
23.1
Overall Length (mm)
61
Barrel Length (In.)
0.91
Inside Diameter (mm)
14.47
Class I Copper Flex Conductor Size (AWG)
36586
Tongue Thickness (mm)
3.6
Stud Hole Size (mm)
12.7
Outer Diameter (mm)
18.03
Class H Copper Flex Conductor Size (AWG)
36586
Tongue Width (mm)
26.9
Wire Strip Length (mm)
25.4
Copper Code Conductor Size (AWG)
36586
Class G Copper Flex Conductor Size (AWG)
36586
Inside Diameter (In.)
0.57
Outer Diameter (In.)
0.71
Wire Strip Length (In.)
1
Tongue Thickness (In.)
0.14
For Stud Size
1 to 2 in
Tongue Width
1.06 in
Barrel Size
Standard
For Wire Size
3/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Orange
Item
Lug Compression Connector
Die Code
14
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connection Material
Tin
Connection Type
1 x Terminal
Features
Angled Connector, Corrosion Resistant
T & B Die Index Number
14
Lug Type
1 Stud Hole Lug
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
Straight
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Burndy Die Index Number
14
Finish/Coating
Tin-Plated
Base Material
Copper
Panduit Die Index Number
P50
Product Material
Copper
Product Name
Terminal Connector
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,3/0 AWG
