  6. Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-38-X - main

Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-38-X

  • Zoro # G0774063

product price:  $13.99
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.19 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAX4/0-38-X
Zoro #
G0774063
UPC #
7498343561
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
Barrel Size
Standard
Tongue Width
1.19 in
Cable Size
4/0 AWG
Width
1.19"
Length
2.53"
Overall Length
2.53 in
Inside Diameter (mm)
16.51
Class K Copper Flex Conductor Size (AWG)
36617
Outer Diameter (mm)
20.57
Stud Hole Size (In.)
44993
DLO Copper Flex Conductor Size (AWG)
36617
Class M Copper Flex Conductor Size (AWG)
36617
Outer Diameter (In.)
0.81
Wire Strip Length (In.)
42370
Tongue Thickness (In.)
0.16
Class I Copper Flex Conductor Size (AWG)
36617
Stud Hole Size (mm)
9.5
Tongue Width (In.)
1.19
Overall Length (mm)
64.3
Tongue Thickness (mm)
4.1
Barrel Length (mm)
26.2
Copper Code Conductor Size (AWG)
36617
Tongue Width (mm)
30.2
Barrel Length (In.)
1.03
Overall Length (In.)
2.53
Class G Copper Flex Conductor Size (AWG)
36617
Inside Diameter (In.)
0.65
Class H Copper Flex Conductor Size (AWG)
36617
Wire Strip Length (mm)
26.9

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
15
Color Code
Purple
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Angled Connector, Corrosion Resistant
Tongue Type
Standard
Panduit Die Index Number
P54
Base Material
Copper
Burndy Die Index Number
15
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
T & B Die Index Number
15
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Lug Type
1 Stud Hole Lug
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,4/0 AWG
