  11. Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-38H-X - main

Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-38H-X

  • Zoro # G0774072

product price: $18.25
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Standard Barrel
Width
1.19"
Material
Copper
Length
2.26"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX4/0-38H-X
Zoro #
G0774072
UPC #
7498343562
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.19"
Length
2.26"
Overall Length
2.26 in
Inside Diameter (mm)
16.51
Copper Code Conductor Size (AWG)
36617
DLO Copper Flex Conductor Size (AWG)
36617
Barrel Length (In.)
1.03
Tongue Thickness (In.)
0.16
Stud Hole Size (In.)
44993
Tongue Width (mm)
30.2
Stud Hole Size (mm)
9.5
Outer Diameter (In.)
0.81
Wire Strip Length (mm)
26.9
Inside Diameter (In.)
0.65
Class K Copper Flex Conductor Size (AWG)
36617
Overall Length (In.)
2.26
Overall Length (mm)
57.4
Wire Strip Length (In.)
42370
Tongue Thickness (mm)
4.1
Barrel Length (mm)
26.2
Outer Diameter (mm)
20.57
Class M Copper Flex Conductor Size (AWG)
36617
Tongue Width (In.)
1.19
Class H Copper Flex Conductor Size (AWG)
36617
Class G Copper Flex Conductor Size (AWG)
36617
Class I Copper Flex Conductor Size (AWG)
36617
Tongue Width
1.19 in
For Wire Size
4/0 AWG
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Purple
Item
Lug Compression Connector
Die Code
15
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, 45° Angled Connector
Tongue Type
Standard
Burndy Die Index Number
15
Lug Type
1 Stud Hole Lug
Finish/Coating
Tin-Plated
Panduit Die Index Number
P54
UL Temperature Rating (°C)
90
Tongue Angle
45 Degrees Angled
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
Base Material
Copper
T & B Die Index Number
15
Connector Details
1 x Terminal
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG
