  11. Lug Compression Connector, 500 kcmil Max, Long Barrel, Copper, Brown
Panduit Lug Compression Connector, 500 kcmil Max, Long Barrel, Copper, Brown LCB500-58-6 - main

Lug Compression Connector, 500 kcmil Max, Long Barrel, Copper, Brown

  • Mfr # LCB500-58-6

  • Zoro # G0412795

product price: $29.99
/ea

Key Features

For Wire Size
500 kcmil
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
1.54 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCB500-58-6
Zoro #
G0412795
UPC #
7498390165
Country of Origin
Mexico

Dimensions

For Wire Size
500 kcmil
Barrel Size
Long
Tongue Width
1.54 in
Cable Size
500 kcmil
Width
1.54"
Length
4.74"
Overall Length
4.74 in
Stud Hole Size (In.)
45054
Barrel Length (mm)
63.5
Tongue Width (mm)
39.1
Stud Hole Size (mm)
15.9
Tongue Thickness (mm)
5.6
Overall Length (mm)
120.4
Barrel Length (In.)
2.5
Tongue Width (In.)
1.54
Copper Code Conductor Size (kcmil)
500
Wire Strip Length (mm)
65.1
Wire Strip Length (In.)
2.56
Tongue Thickness (In.)
0.22
Overall Length (In.)
4.74

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
20
Color Code
Brown
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Angled Connector, Corrosion Resistant
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Base Material
Copper
Burndy Die Index Number
20
Tongue Type
Standard
Finish/Coating
Tin-Plated
Panduit Die Index Number
P87
Connector Plating
Tin
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Material
Copper
Product Class
Wire Termination

Description

One-hole, long barrel lug, 500 kcmil cable, 5/8 stud hole.
