  6. Lug Compression Connector, 500 kcmil Max, Standard Barrel, Copper, Brown
Panduit Lug Compression Connector, 500 kcmil Max, Standard Barrel, Copper, Brown LCAN500-38-6 - main

Lug Compression Connector, 500 kcmil Max, Standard Barrel, Copper, Brown

  • Mfr # LCAN500-38-6

  • Zoro # G0772943

product price:  $27.59
/ea

Key Features

For Wire Size
500 kcmil
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.06 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCAN500-38-6
Zoro #
G0772943
UPC #
7498360347
Country of Origin
Mexico

Dimensions

For Wire Size
500 kcmil
Barrel Size
Standard
Tongue Width
1.06 in
Cable Size
500 kcmil
Length
3.39 in
Width
1.06 in
Overall Length
3.39 in
Barrel Length (In.)
1.75
Tongue Width (mm)
26.9
Copper Code Conductor Size (kcmil)
500
Wire Strip Length (In.)
1.8125
Tongue Width (In.)
1.06
Overall Length (mm)
86.1
Overall Length (In.)
3.39
Tongue Thickness (In.)
0.23
Tongue Thickness (mm)
5.8
Stud Hole Size (In.)
44993
Wire Strip Length (mm)
46
Stud Hole Size (mm)
9.5
Barrel Length (mm)
44.5

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
20
Color Code
Brown
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Angled Connector, Corrosion Resistant
Panduit Die Index Number
P87
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Burndy Die Index Number
20
Tongue Type
Narrow
T & B Die Index Number
87
UL Temperature Rating (°C)
90
Base Material
Copper
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Wire Termination

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
