  11. Lug Compression Connector, 6 AWG Max, Standard Barrel, Copper, Blue
Panduit Lug Compression Connector, 6 AWG Max, Standard Barrel, Copper, Blue LCA6-14F-L - main

Lug Compression Connector, 6 AWG Max, Standard Barrel, Copper, Blue

  • Mfr # LCA6-14F-L

  • Zoro # G0772219

product price: $3.47
/ea
Sold in multiples of 2 for $6.94

Key Features

Cable Size
6 AWG
Connector Type
Standard Barrel
Width
0.48"
Material
Copper
Length
1.03"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCA6-14F-L
Zoro #
G0772219
UPC #
7498355902
Country of Origin
Mexico

Dimensions

Cable Size
6 AWG
Width
0.48"
Length
1.03"
Overall Length
1.03 in
Stud Hole Size (In.)
44930
Tongue Width (mm)
11.4
Stud Hole Size (mm)
6.4
Copper Code Conductor Size (AWG)
6
Wire Strip Length (mm)
22.2
Barrel Length (mm)
20.6
Tongue Thickness (mm)
2
Barrel Length (In.)
0.81
Overall Length (In.)
1.03
Tongue Width (In.)
0.48
Tongue Thickness (In.)
0.08
Overall Length (mm)
26.2
Barrel Size
Standard
Tongue Width
0.48 in
For Wire Size
6 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Blue
Item
Lug Compression Connector
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
7
Connection Type
1 x Terminal
Connection Material
Tin
Features
90° Angled Connector, Corrosion Resistant
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Tongue Type
Standard
UL Temperature Rating (°C)
90
Burndy Die Index Number
7
Panduit Die Index Number
P24
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
90 Degrees Angled
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,No.6 AWG
