Panduit Mechanical Connector, 4-14 AWG PCSB4-3S-12Y - main

Mechanical Connector, 4-14 AWG

  • Mfr # PCSB4-3S-12Y

  • Zoro # G0781772

product price: $20.19
/ea

Key Features

Number of Ports
3
Insulation Material
Clear PVC
Length
1.8"
Width
1.3"
Overall Length
1.76 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PCSB4-3S-12Y
Zoro #
G0781772
UPC #
7498359757
Country of Origin
United States

Dimensions

Length
1.8"
Width
1.3"
Overall Length
1.76 in
Height
1.2"
Overall Width (In.)
1.25
Maximum Copper Conductor Size (AWG)
10
Minimum Aluminum Conductor Size (AWG)
14
Maximum Copper Conductor Size (AWG SOL)
10
Overall Width (mm)
31.8
Minimum Copper Conductor Size (AWG STR)
14
Overall Height (mm)
31.7
Wire Strip Length (In.)
0.56
Hex Size (mm)
3.17
Overall Length (mm)
44.7
Maximum Copper Conductor Size (AWG STR)
4
Minimum Copper Conductor Size (AWG SOL)
14
Overall Length (In.)
1.76
Overall Height (In.)
1.25
Wire Strip Length (mm)
14.2
For Wire Size
4-14 AWG

Details

Item
Mechanical Connector,4-14 AWG
Number of Ports
3
Insulation Material
Clear PVC
Features
Single Sided
Application
Aluminum or Copper Code Conductors
Maximum Voltage (V)
600
Product Type
Multi-Tap Mechanical Connectors, Single Sided
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
Standards Met
UL listed and CSA certified for use up to 600V & Temperature Rated to 90°C
Base Material
Aluminum
Note
PCSB4-3S-12Y replaces PCSB4-3S-12
Product Line
Pan-Lug
Product Material
Polyvinyl Chloride (PVC)
Product Color
Clear
Product Name
Pan-Lug Terminal Connector
Connector Details
Multi-tap Terminal
Product Class
Mechanical Lugs
Body Material
Aluminum
Head Style
Hex
Color
Clear
For Conductor Material
Aluminum or Copper

Description

Mechanical Connector,4-14 AWG
