  11. One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green
Panduit One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green LCA1-56H-E - main

One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green

  • Mfr # LCA1-56H-E

  • Zoro # G0771430

product price: $9.79
/ea

Key Features

Cable Size
1 AWG
Connector Type
Standard Barrel
Width
0.7"
Material
Copper
Length
1.62"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCA1-56H-E
Zoro #
G0771430
UPC #
7498355831
Country of Origin
Mexico

Dimensions

Cable Size
1 AWG
Width
0.7"
Length
1.62"
Overall Length
1.62 in
Barrel Length (mm)
22.4
Tongue Width (mm)
17.8
Wire Strip Length (mm)
23.8
Copper Code Conductor Size (AWG)
1
Tongue Thickness (In.)
0.11
Barrel Length (In.)
0.88
Stud Hole Size (In.)
45062
Overall Length (mm)
41.1
Tongue Thickness (mm)
2.8
Stud Hole Size (mm)
7.9
Overall Length (In.)
1.62
Tongue Width (In.)
0.7
Tongue Width
0.70 in
For Wire Size
1 AWG
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Green
Item
One-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
11
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, 45° Angled Connector
Burndy Die Index Number
11
Tongue Angle
45 Degrees Angled
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Panduit Die Index Number
P37
Base Material
Copper
Tongue Type
Standard
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,No.1 AWG
