  11. One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green
Panduit One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green LCAN1-14-E - main

One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green

  • Mfr # LCAN1-14-E

  • Zoro # G0772867

product price: $9.39
/ea

Key Features

Cable Size
1 AWG
Connector Type
Standard Barrel
Width
0.47"
Material
Copper
Length
1.79"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAN1-14-E
Zoro #
G0772867
UPC #
7498360332
Country of Origin
Mexico

Dimensions

Cable Size
1 AWG
Width
0.47"
Length
1.79"
Overall Length
1.79 in
Tongue Width (mm)
11.9
Copper Code Conductor Size (AWG)
1
Stud Hole Size (In.)
44930
Overall Length (In.)
1.79
Tongue Thickness (mm)
3
Tongue Width (In.)
0.47
Overall Length (mm)
45.5
Wire Strip Length (In.)
15/16
Barrel Length (mm)
22.4
Tongue Thickness (In.)
0.12
Barrel Length (In.)
0.88
Stud Hole Size (mm)
6.4
Wire Strip Length (mm)
23.8
Barrel Size
Standard
For Wire Size
1 AWG
Tongue Width
0.47 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Green
Item
One-Hole Compression Lug
Die Code
11
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connection Material
Tin
Connection Type
1 x Terminal
Features
Angled Connector, Corrosion Resistant
T & B Die Index Number
37
Tongue Angle
Straight
Maximum Voltage (kV)
35
Base Material
Copper
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
Product Type
Copper Compression Connectors - Lugs
Tongue Type
Narrow
Burndy Die Index Number
11
Panduit Die Index Number
P37
Product Name
Terminal Connector
Connector Details
1 x Terminal
Connector Plating
Tin
Product Material
Copper
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,No.1 AWG
