  11. One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Black LCDX2/0-12-X - main

One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Black

  • Mfr # LCDX2/0-12-X

  • Zoro # G604858691

product price: $14.15
/ea

Key Features

Material
Copper
Color Code
Black
Tool Type
Compression Connectors - Lugs
Hole Center to Center
44563
Overall Length
4.19 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCDX2/0-12-X
Zoro #
G604858691
UPC #
7498342383
Country of Origin
Mexico

Dimensions

Overall Length
4.19 in
Tongue Thickness (mm)
3.3
Wire Strip Length (In.)
45115
Tongue Width (In.)
0.96
Class K Copper Flex Conductor Size (AWG)
36557
Copper Code Conductor Size (AWG)
36557
Class H Copper Flex Conductor Size (AWG)
36557
Class G Copper Flex Conductor Size (AWG)
36557
Tongue Width (mm)
24.4
Class M Copper Flex Conductor Size (AWG)
36557
DLO Copper Flex Conductor Size (AWG)
36557
Wire Strip Length (mm)
22
Stud Hole Size (In.)
1 to 2
Barrel Length (mm)
21.1
Class I Copper Flex Conductor Size (AWG)
36557
Overall Length (mm)
106.4
Tongue Thickness (In.)
0.13
Stud Hole Size (mm)
12.7
Barrel Length (In.)
0.83
Overall Length (In.)
4.19
Barrel Size
Standard
For Stud Size
1 to 2 in
Tongue Width
0.96 in

Details

Material
Copper
Color Code
Black
Tool Type
Compression Connectors - Lugs
Hole Center to Center
44563
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Item
One-Hole Compression Lug
Die Code
13
Stud Hole Spacing (In.)
1.75
Stud Hole Spacing (mm)
44.5
Maximum Voltage (kV)
35
Tongue Angle
Straight
Base Material
Copper
T & B Die Index Number
45
UL Temperature Rating (°C)
90
Panduit Die Index Number
P45
Tongue Type
Standard
Finish/Coating
Tin-Plated
Burndy Die Index Number
13
Product Type
Compression Connectors - Lugs
Product Class
Wire Termination
For Conductor Material
Copper

Description

Two-hole, flex lug, 2/0 AWG wire, 1/2 stud hole, 1.75 hole spacing.
