  11. One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Blue
Panduit One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Blue LCAX350-12F-6 - main

One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Blue

  • Mfr # LCAX350-12F-6

  • Zoro # G2798944

product price: $32.75
/ea

Key Features

For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
Tongue Width
1.54 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX350-12F-6
Zoro #
G2798944
UPC #
7498343593
Country of Origin
Mexico

Dimensions

For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.54 in
Length
1.7"
Overall Length
2.48 in
Overall Length (mm)
63
Barrel Length (mm)
32.8
Wire Strip Length (mm)
34.9
Tongue Thickness (In.)
0.22
Class I Copper Flex Conductor Size (kcmil)
350
Copper Code Conductor Size (kcmil)
350
Tongue Width (In.)
1.54
Barrel Length (In.)
1.29
Stud Hole Size (mm)
12.7
Class H Copper Flex Conductor Size (kcmil)
350
Class K Copper Flex Conductor Size (kcmil)
350
Overall Length (In.)
2.48
Stud Hole Size (In.)
1 to 2
Class M Copper Flex Conductor Size (kcmil)
350
Class G Copper Flex Conductor Size (kcmil)
350
Tongue Thickness (mm)
5.6
Tongue Width (mm)
39.1

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
90 Degrees Angled
Die Code
19
Color Code
Blue
Features
90° Angled Connector, Corrosion Resistant
Burndy Die Index Number
19
Panduit Die Index Number
P76
Finish/Coating
Tin-Plated
Base Material
Copper
Tongue Type
Standard
UL Temperature Rating (°C)
90
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
Connector Details
1 x Terminal
Connector Plating
Tin
Product Material
Copper
Product Name
Terminal Connector
Product Class
Wire Termination

Description

Copper Compression Lug, 1 Hole, 350 kcmil Flex, 1/2 (12.7mm) Stud, 90° Bent
