One-Hole Compression Lug, 1 to 2 in Stud, Standard Barrel, Copper, Red
- Mfr # LCA350-12H-X
- Zoro # G2750626
product price:
$
26.89
/ea
Key Features
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
Tongue Width
1.28 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCA350-12H-X
- Zoro #
- G2750626
- UPC #
- 7498386968
- Country of Origin
- Mexico
- Item
- One-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Tongue Angle
- 45 Degrees Angled
- Die Code
- 18
- Color Code
- Red
- Standards
- C22.2 No. 65-13, 486A-486B File #E52164
- Features
- Corrosion Resistant, 45° Angled Connector
- Finish/Coating
- Tin-Plated
- UL Temperature Rating (°C)
- 90
- Maximum Voltage (kV)
- 35
- Base Material
- Copper
- Tongue Type
- Standard
- Product Type
- Copper Compression Connectors - Lugs
- Panduit Die Index Number
- P71
- Burndy Die Index Number
- 18
- Product Material
- Copper
- Product Name
- Terminal Connector
- Connector Details
- 1 x Terminal
- Connector Plating
- Tin
- Product Class
- Wire Termination
Dimensions
- For Stud Size
- 1 to 2 in
- Barrel Size
- Standard
- Tongue Width
- 1.28 in
- Overall Length
- 2.7 in
- Length
- 2.5"
- Wire Strip Length (In.)
- 1.5
- Tongue Thickness (mm)
- 4.3
- Barrel Length (In.)
- 1.44
- Overall Length (mm)
- 68.6
- Barrel Length (mm)
- 36.6
- Overall Length (In.)
- 2.7
- Wire Strip Length (mm)
- 38.1
- Tongue Width (In.)
- 1.28
- Tongue Width (mm)
- 32.5
- Stud Hole Size (mm)
- 12.7
- Stud Hole Size (In.)
- 1 to 2
- Tongue Thickness (In.)
- 0.17
- Copper Code Conductor Size (kcmil)
- 350
Description
Copper Compression Lug, 1 Hole, 350 kcmil, 1/2 (12.7mm) Stud, 45° Bent
