  11. One-Hole Compression Lug, 1/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Pink
Panduit One-Hole Compression Lug, 1/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Pink LCD1/0-12-X - main

One-Hole Compression Lug, 1/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Pink

  • Mfr # LCD1/0-12-X

  • Zoro # G0777222

product price: $12.85
/ea

Key Features

Cable Size
1/0 AWG
Connector Type
Standard Barrel
Width
0.8"
Material
Copper
Length
4-1/4"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD1/0-12-X
Zoro #
G0777222
UPC #
7498390090
Country of Origin
Mexico

Dimensions

Cable Size
1/0 AWG
Width
0.8"
Length
4-1/4"
Overall Length
4.25 in
Tongue Thickness (mm)
3
Stud Hole Size (mm)
12.7
Wire Strip Length (In.)
1
Overall Length (mm)
107.9
Tongue Width (mm)
20.3
Overall Length (In.)
4.25
Barrel Length (In.)
0.94
Wire Strip Length (mm)
25.4
Stud Hole Size (In.)
1 to 2
Barrel Length (mm)
23.9
Copper Code Conductor Size (AWG)
36526
Tongue Thickness (In.)
0.12
Tongue Width (In.)
0.8
For Wire Size
1/0 AWG
Tongue Width
0.80 in
Barrel Size
Standard
For Stud Size
1 to 2 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Pink
Item
One-Hole Compression Lug
Die Code
12
Features
Corrosion Resistant
Connection Type
1 x Terminal
Connection Material
Tin
Panduit Die Index Number
P42
Maximum Voltage (kV)
35
Base Material
Copper
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
12
Stud Hole Spacing (mm)
44.5
Stud Hole Spacing (In.)
1.75
Tongue Type
Standard
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,1/0 AWG
