  11. One-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Black LCAF1/0-38-X - main

One-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Black

  • Mfr # LCAF1/0-38-X

  • Zoro # G0772307

product price: $8.25
/ea

Key Features

Cable Size
1/0 AWG
Connector Type
Flared Barrel
Width
0.85"
Material
Copper
Length
2.52"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAF1/0-38-X
Zoro #
G0772307
UPC #
7498355771
Country of Origin
Mexico

Dimensions

Cable Size
1/0 AWG
Width
0.85"
Length
2.52"
Overall Length
2.52 in
Tongue Thickness (mm)
3.3
Class K Copper Flex Conductor Size (AWG)
36526
Barrel Length (In.)
1.35
DLO Copper Flex Conductor Size (AWG)
36526
Class M Copper Flex Conductor Size (AWG)
36526
Wire Strip Length (mm)
36.5
Tongue Thickness (In.)
0.13
Overall Length (In.)
2.52
Tongue Width (In.)
0.85
Barrel Length (mm)
34.3
Stud Hole Size (In.)
44993
Tongue Width (mm)
21.6
Stud Hole Size (mm)
9.5
Overall Length (mm)
64
For Wire Size
1/0 AWG
Tongue Width
0.85 in
Barrel Size
Standard

Details

Connector Type
Flared Barrel
Material
Copper
Color Code
Black
Item
One-Hole Compression Lug
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, Angled Connector
Tongue Type
Standard
Tongue Angle
Straight
UL Temperature Rating (°C)
90
Maximum Voltage (kV)
35
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Panduit Die Index Number
P45
Finish/Coating
Tin-Plated
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,1/0 AWG
